FCC ID QGGIPA248M
Base Station Indoor
by Mavenir IPA UK Ltd
Grantee Code: QGG Product Code: IPA248M
Latest application date: 2016-07-22
Device Images
FCC ID Device Details
| FCC ID | QGGIPA248M |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QGG |
| Product Code | IPA248M |
| Applicant Business | Mavenir IPA UK Ltd 🇬🇧 |
| Related Domains |  mavenir.com |
| Equipment Class | Base Station Indoor |
| Test Firm | Compliance Engineering Ireland Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 736.5-743.5 MHz | Original Equipment | 2016-07-22 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Antenna instructions | Users Manual | 2016-07-22 | PDF 29.7 KB |
| User Manual | Users Manual | 2016-07-22 | PDF 1.4 MB |
| Internal Photos | Internal Photos | 2016-07-22 | PDF 4.5 MB |
| External Photos | External Photos | 2016-07-22 | PDF 723.4 KB |
| Label | ID Label/Location Info | 2016-07-22 | PDF 233.8 KB |
| Label Location | ID Label/Location Info | 2016-07-22 | PDF 107.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-07-22 | PDF 406.1 KB |
| Test Report | Test Report | 2016-07-22 | PDF 5.2 MB |
| Agent Aut and Confidentiality | Cover Letter(s) | 2016-07-22 | PDF 109.2 KB |
| Model Variants | Cover Letter(s) | 2016-07-22 | PDF 29.9 KB |
| RF Exposure | RF Exposure Info | 2016-07-22 | PDF 114.2 KB |
| RF Exposure antenna gains | RF Exposure Info | 2016-07-22 | PDF 113.1 KB |
| Block diagram Metadata only | Block Diagram | PDF 785.5 KB | |
| Schematics Metadata only | Schematics | PDF 1.3 MB | |
| Operational Description Metadata only | Operational Description | PDF 1.3 MB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 524.1 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 279.6 KB |
Application Information
| Application ID | a7Deq11oZ5X1B8o6PF5OfQ== |
|---|---|
| Final Action Date | 2016-07-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007280951 |
| Model | IPA248M |
| Frequency Range | 736.5-743.5 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | Base Station Indoor |
| Responsible Party | Adrian Pearce, Engineering Director, adrian.pearce@mavenir.com , +441954713700 |
| Agent | Compliance Engineering Ireland, john.mcauley@cei.ie  |
| Test Firm | John McAuley, Compliance Engineering Ireland Ltd., john.mcauley@cei.ie , 353-1-8256722 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is total aggregate conducted power. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC Bureaus(s), including antenna co-location requirements of 1.1307(b). |
