FCC ID QIPPLS8-USR4
GSM, WCDMA, LTE Module
by THALES DIS AlS Deutschland GmbH
Grantee Code: QIP Product Code: PLS8USR4
Latest application date: 2017-04-04
Device Images
FCC ID Device Details
| FCC ID | QIPPLS8-USR4 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QIP |
| Product Code | PLS8USR4 |
| Applicant Business | THALES DIS AlS Deutschland GmbH 🇩🇪 |
| Related Domains |  thalesgroup.com |
| Equipment Class | GSM, WCDMA, LTE Module |
| Test Firm | CETECOM GmbH |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 706.5-713.5 MHz | Change in identification of presently authorized equipment. Original FCC ID: QIPPLS8-USR3 Grant Date: 10/26/2015 | 2017-04-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-04 | PDF 788.1 KB |
| External_photos | External Photos | 2017-04-04 | PDF 179 KB |
| Label and label_location | ID Label/Location Info | 2017-04-04 | PDF 166.8 KB |
| Cover Letter_fcc_request_change_identification | Cover Letter(s) | 2017-04-04 | PDF 48.9 KB |
Application Information
| Application ID | RZyUTT7PSZDvle7IapXg8w== |
|---|---|
| Final Action Date | 2017-04-04 |
| Application Purpose | Change in identification of presently authorized equipment. Original FCC ID: QIPPLS8-USR3 Grant Date: 10/26/2015 |
| Applicant FRN | 0019578749 |
| Model | PLS8-USR4 |
| Equipment Class | JBP - Part 15 Class B Computing Device Peripheral |
| Device Description | GSM, WCDMA, LTE Module |
| Responsible Party | Axel Heike, Manager Certifications, axel.heike@thalesgroup.com , 004930311028146 |
| Test Firm | Niels Jess, CETECOM GmbH, niels.jess@cetecom.com  , +49 2054 9519 603 |
| TCB Email | tcb-essen@cetecom.com |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| RZyUTT7PSZDvle7IapXg8w== | 2017-04-04 | Change in identification of presently authorized equipment. Original FCC ID: QIPPLS8-USR3 Grant Date: 10/26/2015 |
| 0CHTcO/RrsHDFO1kLOIEMA== | 2017-04-04 | Change in identification of presently authorized equipment. Original FCC ID: QIPPLS8-USR3 Grant Date: 10/26/2015 |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules |
|---|---|---|---|---|
| 706.5-713.5 MHz | 0.158 | 0.01ppm | 4M51G7D | 27 |
| 706.5-713.5 MHz | 0.12 | 0.01ppm | 4M59W7D | 27 |
| 709-711 MHz | 0.144 | 0.01ppm | 9M06G7D | 27 |
| 709-711 MHz | 0.112 | 0.01ppm | 9M06W7D | 27 |
| 824.7-848.3 MHz | 0.178 | 0.01ppm | 1M09G7D | 22H |
| 824.7-848.3 MHz | 0.141 | 0.01ppm | 1M10W7D | 22H |
| 826.4-846.6 MHz | 0.244 | 0.02ppm | 4M17F9W | 22H |
| 829-844 MHz | 0.166 | 0.01ppm | 9M06G7D | 22H |
| 829-844 MHz | 0.132 | 0.01ppm | 9M06W7D | 22H |
| 1712.4-1752.6 MHz | 0.262 | 0.02ppm | 4M16F9W | 27 |
| 1712.5-1752.5 MHz | 0.159 | 0.02ppm | 4M50W7D | 27 |
| 1715-1750 MHz | 0.2 | 0.01ppm | 9M06G7D | 27 |
| 1720-1745 MHz | 0.178 | 0.01ppm | 19M9G7D | 27 |
| 1720-1745 MHz | 0.135 | 0.01ppm | 17M9W7D | 27 |
| 1850.2-1909.8 MHz | 1 | 0.02ppm | 247KGXW | 24E |
| 1850.2-1909.8 MHz | 0.83 | 0.02ppm | 247KG7W | 24E |
| 1852.4-1907.6 MHz | 0.264 | 0.02ppm | 4M17F9W | 24E |
| 1852.5-1907.5 MHz | 0.182 | 0.01ppm | 4M53G7D | 24E |
| 1852.5-1907.5 MHz | 0.141 | 0.01ppm | 4M51W7D | 24E |
| 1860-1900 MHz | 0.156 | 0.01ppm | 17M9G7D | 24E |
| 1860-1900 MHz | 0.129 | 0.01ppm | 17M9W7D | 24E |
Grants
TCB Grant - Application RZyUTT7PSZDvle7IapXg8w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CETECOM GmbH Im Teelbruch 116 45219 Essen, Germany |
Date of Grant: 04/04/2017 Application Dated: 04/04/2017 |
| THALES DIS AlS Deutschland GmbH |
| Siemensdamm 50 |
| Berlin, 13629 Germany |
| Attention: Axel Heike , Manager Certifications |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QIPPLS8-USR4 |
| Name of Grantee: | THALES DIS AlS Deutschland GmbH |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | GSM, WCDMA, LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
EAS Grant - Application RZyUTT7PSZDvle7IapXg8w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
THALES DIS AlS Deutschland GmbH Siemensdamm 50 Berlin, 13629 Germany |
Date of Grant: 04/04/2017 Application Dated: 04/04/2017 |
| Attention: Axel Heike , Manager Certifications |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QIPPLS8-USR4 |
| Name of Grantee: | THALES DIS AlS Deutschland GmbH |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | GSM, WCDMA, LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CETECOM GmbH Im Teelbruch 116 45219 Essen, Germany |
Date of Grant: 04/04/2017 Application Dated: 04/04/2017 |
| THALES DIS AlS Deutschland GmbH |
| Siemensdamm 50 |
| Berlin, 13629 Germany |
| Attention: Axel Heike , Manager Certifications |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QIPPLS8-USR4 |
| Name of Grantee: | THALES DIS AlS Deutschland GmbH |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | GSM, WCDMA, LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.84 | 0.02 PM | 245KGXW | |
| 22H | 824.2 - 848.8 | 0.9 | 0.02 PM | 245KG7W | |
| 22H | 826.4 - 846.6 | 0.244 | 0.02 PM | 4M17F9W | |
| 22H | 824.7 - 848.3 | 0.178 | 0.01 PM | 1M09G7D | |
| 22H | 824.7 - 848.3 | 0.141 | 0.01 PM | 1M10W7D | |
| 22H | 829.0 - 844.0 | 0.166 | 0.01 PM | 9M06G7D | |
| 22H | 829.0 - 844.0 | 0.132 | 0.01 PM | 9M06W7D | |
| 27 | 706.5 - 713.5 | 0.158 | 0.01 PM | 4M51G7D | |
| 27 | 706.5 - 713.5 | 0.12 | 0.01 PM | 4M59W7D | |
| 27 | 709.0 - 711.0 | 0.144 | 0.01 PM | 9M06G7D | |
| 27 | 709.0 - 711.0 | 0.112 | 0.01 PM | 9M06W7D | |
| 27 | 1712.5 - 1752.5 | 0.159 | 0.02 PM | 4M50W7D | |
| 27 | 1715.0 - 1750.0 | 0.2 | 0.01 PM | 9M06G7D | |
| 27 | 1720.0 - 1745.0 | 0.178 | 0.01 PM | 19M9G7D | |
| 27 | 1720.0 - 1745.0 | 0.135 | 0.01 PM | 17M9W7D | |
| 27 | 1712.4 - 1752.6 | 0.262 | 0.02 PM | 4M16F9W | |
| 24E | 1850.2 - 1909.8 | 1.0 | 0.02 PM | 247KGXW | |
| 24E | 1850.2 - 1909.8 | 0.83 | 0.02 PM | 247KG7W | |
| 24E | 1852.4 - 1907.6 | 0.264 | 0.02 PM | 4M17F9W | |
| 24E | 1852.5 - 1907.5 | 0.182 | 0.01 PM | 4M53G7D | |
| 24E | 1852.5 - 1907.5 | 0.141 | 0.01 PM | 4M51W7D | |
| 24E | 1860.0 - 1900.0 | 0.156 | 0.01 PM | 17M9G7D | |
| 24E | 1860.0 - 1900.0 | 0.129 | 0.01 PM | 17M9W7D |
| Output power listed is conducted. This device contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures For mobile and fixed operating configurations the antenna gain, including cable loss must not exceed values as documented in this filing for satisfying RF exposure compliance. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified in Part 22H, 24E and 27. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. OEM integrators must ensure that the end user has no manual instructions to remove or install this module. The Grantee is responsible for providing the documentation required for modular use. |
EAS Grant - Application 0CHTcO/RrsHDFO1kLOIEMA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
THALES DIS AlS Deutschland GmbH Siemensdamm 50 Berlin, 13629 Germany |
Date of Grant: 04/04/2017 Application Dated: 04/04/2017 |
| Attention: Axel Heike , Manager Certifications |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QIPPLS8-USR4 |
| Name of Grantee: | THALES DIS AlS Deutschland GmbH |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | GSM, WCDMA, LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 824.2 - 848.8 | 1.84 | 0.02 PM | 245KGXW | |
| 22H | 824.2 - 848.8 | 0.9 | 0.02 PM | 245KG7W | |
| 22H | 826.4 - 846.6 | 0.244 | 0.02 PM | 4M17F9W | |
| 22H | 824.7 - 848.3 | 0.178 | 0.01 PM | 1M09G7D | |
| 22H | 824.7 - 848.3 | 0.141 | 0.01 PM | 1M10W7D | |
| 22H | 829.0 - 844.0 | 0.166 | 0.01 PM | 9M06G7D | |
| 22H | 829.0 - 844.0 | 0.132 | 0.01 PM | 9M06W7D | |
| 27 | 706.5 - 713.5 | 0.158 | 0.01 PM | 4M51G7D | |
| 27 | 706.5 - 713.5 | 0.12 | 0.01 PM | 4M59W7D | |
| 27 | 709.0 - 711.0 | 0.144 | 0.01 PM | 9M06G7D | |
| 27 | 709.0 - 711.0 | 0.112 | 0.01 PM | 9M06W7D | |
| 27 | 1712.5 - 1752.5 | 0.159 | 0.02 PM | 4M50W7D | |
| 27 | 1715.0 - 1750.0 | 0.2 | 0.01 PM | 9M06G7D | |
| 27 | 1720.0 - 1745.0 | 0.178 | 0.01 PM | 19M9G7D | |
| 27 | 1720.0 - 1745.0 | 0.135 | 0.01 PM | 17M9W7D | |
| 27 | 1712.4 - 1752.6 | 0.262 | 0.02 PM | 4M16F9W | |
| 24E | 1850.2 - 1909.8 | 1.0 | 0.02 PM | 247KGXW | |
| 24E | 1850.2 - 1909.8 | 0.83 | 0.02 PM | 247KG7W | |
| 24E | 1852.4 - 1907.6 | 0.264 | 0.02 PM | 4M17F9W | |
| 24E | 1852.5 - 1907.5 | 0.182 | 0.01 PM | 4M53G7D | |
| 24E | 1852.5 - 1907.5 | 0.141 | 0.01 PM | 4M51W7D | |
| 24E | 1860.0 - 1900.0 | 0.156 | 0.01 PM | 17M9G7D | |
| 24E | 1860.0 - 1900.0 | 0.129 | 0.01 PM | 17M9W7D |
| Output power listed is conducted. This device contains functions that are not operational in U.S. Territories. This filing is only applicable for US operations. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures For mobile and fixed operating configurations the antenna gain, including cable loss must not exceed values as documented in this filing for satisfying RF exposure compliance. Under no conditions may an antenna gain be used that would exceed the ERP and EIRP power limits as specified in Part 22H, 24E and 27. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. OEM integrators must ensure that the end user has no manual instructions to remove or install this module. The Grantee is responsible for providing the documentation required for modular use. |
