9XM4 Radar Detector Test Report - FCC ID QKL9XM4
FCC ID QKL9XM4
EP0458-1 Technical Report.pdf
Radar Detector
Document preview loads when visible.
Document Details
| FCC ID | QKL9XM4 |
|---|---|
| Document ID | 2566813 |
| Document Type | Test Report |
| Description | EP0458-1 Technical Report.pdf |
| Document Title | Final Report |
| Applicant | Escort Incorporated |
| Equipment Class | Radar Detector |
| Product Code | 9XM4 |
| Application ID | iOu2zHerp5WaDgBTojfsmw== |
| Application Purpose | Original Equipment |
| Application Date | 2015-03-26 |
| Frequency Range | 10475-10575 MHz |
| FRN | 0007508732 |
| Test Firm | BUREAU VERITAS CONSUMER PRODUCTS SERVICES, INC. |
| Certified By | Christopher Reynolds |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/10/2015 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2015-03-26 |
| Available | 2015-03-26 |
| Created | 2015-03-09 |
| Modified | 2015-03-09 |
| Pages | 9 |
| File Type | Adobe Acrobat PDF |
| File Size | 405118 |
| File SHA-256 | 7c2d625ed7e89f8d97ec46cf04101cc65d871c25b4ea6218a0c46f747b31334f |
| PDF Metadata Author | emclogin1 |
| PDF Metadata Producer | emclogin1 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 2566813 |
