ASHKB Proximity Reader with Keypad Block Diagram - FCC ID QNX-ASHKB

FCC ID QNX-ASHKB

Block Diagram

Proximity Reader with Keypad

by Baran Advanced Technologies (1986) Ltd.

Document preview loads when visible.

Document Details

FCC IDQNX-ASHKB
Document ID338469
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleASHKB
ApplicantBaran Advanced Technologies (1986) Ltd.
Equipment ClassProximity Reader with Keypad
Product CodeASHKB
Application ID/4DaBFqot0nIngadJQiJkg==
Application PurposeOriginal Equipment
Application Date2003-07-09
Frequency Range13.56 MHz
FRN0007736168
Test FirmHermon Laboratories Ltd.
Certified ByYossi Ron
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-07-09
Available2003-07-09
Created2003-06-18
Modified2003-06-18
Pages1
File TypeAdobe Acrobat PDF
File Size26495
File SHA-256e52f6ed1d4bb788b68256ce49c8e301685c8365fc2f42562572ff3aa92b5fab7
PDF Metadata AuthorInnaH
PDF Metadata ProducerFinePrint pdfFactory FinePrint pdfFactory v1.17 (Windows XP Hebrew)
FCC.gov SourcesFCC.gov 338469
