511A Wireless LAN USB Adapter Block Diagram - FCC ID QS4-511A

FCC ID QS4-511A

block diagram

Wireless LAN USB Adapter

by 11 Wave Technology Inc.

Document preview loads when visible.

Document Details

FCC IDQS4-511A
Document ID321993
Document TypeBlock Diagram
Descriptionblock diagram
Applicant11 Wave Technology Inc.
Equipment ClassWireless LAN USB Adapter
Product Code511A
Application IDyTyX5cIrm4uCaWB9gzaEMg==
Application PurposeOriginal Equipment
Application Date2003-04-30
Frequency Range2412-2462 MHz
FRN0008140147
Test FirmTraining Research Co., Ltd.
Certified ByM. J. Huang Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-04-30
Available2003-04-30
Created2003-04-09
Modified2003-04-09
Pages1
File TypeAdobe Acrobat PDF
File Size14069
File SHA-2564be4c9df26ea7211ecdd55f37241aedcdbc02b5e7b067b5f2a317defedf1792a
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows)
FCC.gov SourcesFCC.gov 321993
