HNMFGXLC Magnetic Field XL Generator... - FCC ID QUI-HN-MFG-XL-C
FCC ID QUI-HN-MFG-XL-C
Test Photos
Magnetic Field XL Generator with Collision Avoidance Module
Document preview loads when visible.
Document Details
| FCC ID | QUI-HN-MFG-XL-C |
|---|---|
| Document ID | 2812434 |
| Document Type | Test Setup Photos |
| Description | Test Photos |
| Document Title | Test Setup Photosx |
| Applicant | Frederick Energy Products LLC |
| Equipment Class | Magnetic Field XL Generator with Collision Avoidance Module |
| Product Code | HNMFGXLC |
| Application ID | LPDH+oFJbhHuhOsLd4teMQ== |
| Application Purpose | Original Equipment |
| Application Date | 2015-11-14 |
| Frequency Range | 0.073 MHz |
| FRN | 0022148134 |
| Test Firm | Washington Laboratories, Ltd. |
| Certified By | Steve Koster Vice President, Washington Labortories, Ltd |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | Yes |
| Submitted | 2015-11-14 |
| Available | 2015-11-14 |
| Created | 2015-09-03 |
| Modified | 2015-09-03 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 501053 |
| File SHA-256 | dc43870983a535fac4b335ad1ef9c1d2bf5b540baca2cf2f9b6b48bd63c5495d |
| PDF Metadata Author | KarenS |
| PDF Metadata Producer | KarenS Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 2812434, FCC.gov 2812418 |
