DW20R Wireless Systems Test Setup Photos - FCC ID QWHDW20R

FCC ID QWHDW20R

Test setup photos

Wireless Systems

by Music Tribe Commercial MY Sdn. Bhd.

Document preview loads when visible.

Document Details

FCC IDQWHDW20R
Document ID4797329
Document TypeTest Setup Photos
DescriptionTest setup photos
Document TitleBTL-FCCP-1-1712C210B_2.4G SRD R00
ApplicantMusic Tribe Commercial MY Sdn. Bhd.
Equipment ClassWireless Systems
Product CodeDW20R
Application IDSHUY4dbjfQts5FPyk3OZcg==
Application PurposeOriginal Equipment
Application Date2020-07-08
Frequency Range2406-2475 MHz
FRN0022048235
Test FirmBTL Inc.
Certified ByKane Xin Innovation Compliance EMC
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-07-08
Available2020-07-08
Created2020-07-03
Modified2020-07-03
Pages4
File TypeAdobe Acrobat PDF
File Size770452
File SHA-2562f9cf353f4e022fc62a60cf6d820c501a773f08b16b5effcf2f45d9c6a3b582e
PDF Metadata AuthorCatherine
PDF Metadata ProducerCatherine Acrobat Distiller 19.0 (Windows)
FCC.gov SourcesFCC.gov 4797329
