FCC ID QWO-SWA51
SWA51 5GHz Wireless Module
by Rayson Technology Co., Ltd.
Grantee Code: QWO Product Code: SWA51
Latest application date: 2016-01-29
Device Images
FCC ID Device Details
| FCC ID | QWO-SWA51 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QWO |
| Product Code | SWA51 |
| Applicant Business | Rayson Technology Co., Ltd. 🇹🇼 |
| Related Domains |  rayson.com |
| Equipment Class | SWA51 5GHz Wireless Module |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5161.35-5239.35 MHz | Original Equipment | 2016-01-29 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual rev 2.pdf | Users Manual | 2016-01-29 | PDF 776.4 KB |
| Internal Photos.pdf | Internal Photos | 2016-01-29 | PDF 883.8 KB |
| External Photos.pdf | External Photos | 2016-01-29 | PDF 875 KB |
| ID Label Location Information rev.pdf | ID Label/Location Info | 2016-01-29 | PDF 143.9 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2016-01-29 | PDF 278.3 KB |
| Test Report rev.pdf | Test Report | 2016-01-29 | PDF 620.1 KB |
| Attestation statement - Channel and Mode Declaration.pdf | Attestation Statements | 2016-01-29 | PDF 447.7 KB |
| Confidentiality Request - Long Term rev.pdf | Cover Letter(s) | 2016-01-29 | PDF 113.4 KB |
| Cover Letter - Agent Authorization.pdf | Cover Letter(s) | 2016-01-29 | PDF 561.8 KB |
| Cover letter - Modular Approval Request.pdf | Cover Letter(s) | 2016-01-29 | PDF 18.1 KB |
| RF Exposure Information (MPE).pdf | RF Exposure Info | 2016-01-29 | PDF 357.2 KB |
Application Information
| Application ID | u90KPGOv5pGHoa9L4J2Aig== |
|---|---|
| Final Action Date | 2016-01-29 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0008451718 |
| Model | -SWA51 |
| Frequency Range | 5161.35-5239.35 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | SWA51 5GHz Wireless Module |
| Responsible Party | Ben Pen, Manager, benpen@rayson.com , 886-3-563-3666 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@tw.bureauveritas.com  , 886-3-3183232 |
| TCB Email | certification@curtis-straus.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| u90KPGOv5pGHoa9L4J2Aig== | 2016-01-29 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application u90KPGOv5pGHoa9L4J2Aig==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 01/29/2016 Application Dated: 01/29/2016 |
| Rayson Technology Co., Ltd. |
| 1F No. 9 R&D, II, Science-Based Industrial Park |
| Hsin-Chu, Taiwan |
| Attention: Ben Pen , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWO-SWA51 |
| Name of Grantee: | Rayson Technology Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | SWA51 5GHz Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5161.35 - 5239.35 | 0.003 | ||
| 38 | 15E | 5736.35 - 5814.35 | 0.004 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured, installed or imported after the June 1, 2016 transition deadline. |
EAS Grant - Application u90KPGOv5pGHoa9L4J2Aig==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Rayson Technology Co., Ltd. 1F No. 9 R&D, II, Science-Based Industrial Park Hsin-Chu, Taiwan |
Date of Grant: 01/29/2016 Application Dated: 01/29/2016 |
| Attention: Ben Pen , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWO-SWA51 |
| Name of Grantee: | Rayson Technology Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | SWA51 5GHz Wireless Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5161.35 - 5239.35 | 0.003 | ||
| 38 | 15E | 5736.35 - 5814.35 | 0.004 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure condition. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product guidelines. Approval is limited to OEM installation only. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured, installed or imported after the June 1, 2016 transition deadline. |
