FCC ID QWP-50670EX
Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment
by Cambium Networks Limited
Grantee Code: QWP Product Code: 50670EX
Latest application date: 2017-03-30
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 4942.5-4987.5 MHz | Change in identification of presently authorized equipment. Original FCC ID: QWP-45700 Grant Date: 06/02/2015 | 2017-03-30 |
| 5156.25-5247.5 MHz | Change in identification of presently authorized equipment. Original FCC ID: QWP-45700 Grant Date: 06/02/2015 | 2017-03-30 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| External Photos | External Photos | 2017-03-30 | PDF 1.2 MB |
| Label detail | ID Label/Location Info | 2017-03-30 | PDF 91.1 KB |
| Label location | ID Label/Location Info | 2017-03-30 | PDF 184.5 KB |
| Authorisation Letter | Cover Letter(s) | 2017-03-30 | PDF 129.2 KB |
| Change of FCC ID Request Letter | Cover Letter(s) | 2017-03-30 | PDF 134 KB |
| SDR software security info Metadata only | SDR Software/Security Inf | PDF 64.7 KB | |
| SDR software security info Metadata only | SDR Software/Security Inf | PDF 60.7 KB |
Application Information
| Application ID | mk6WAF7xTeOrbnTv1uCCEQ== |
|---|---|
| Final Action Date | 2017-03-30 |
| Application Purpose | Change in identification of presently authorized equipment. Original FCC ID: QWP-45700 Grant Date: 06/02/2015 |
| Applicant FRN | 0021132279 |
| Model | 50670EX |
| Frequency Range | 4942.5-4987.5 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment |
| Responsible Party | Don Reid, Mr, Don.Reid@Cambiumnetworks.com  , +44 1364 655667 |
| Technical Contact | Donald Reid, Cambium Networks Limited, don.reid@cambiumnetworks.com , 00441364655667 |
| Non-Technical Contact | Mark Thomas, Cambium Networks Limited, mark.thomas@cambiumnetworks.com , 00441364655586 |
| Test Firm | Darren Rust, UL VS Ltd, darren.rust@ul.com  , +44 1256 31 2119 |
| TCB Email | certification@ul.com |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | Yes |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Output power is conducted. This device supports MIMO operations as described in this filing. The device supports 5MHz, 10MHz, 15MHz and 20MHz, bandwidths. Professional installation is required for devices with external antenna connectors. To comply with RF exposure requirements antennas must be installed to ensure a minimum separation distance of 2.07m from persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| mk6WAF7xTeOrbnTv1uCCEQ== | 2017-03-30 | Change in identification of presently authorized equipment. Original FCC ID: QWP-45700 Grant Date: 06/02/2015 |
| 1sJkMcWXD/fgzxSLU/QDZQ== | 2017-03-30 | Change in identification of presently authorized equipment. Original FCC ID: QWP-45700 Grant Date: 06/02/2015 |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 4942.5-4987.5 MHz | 0.42 | 1.6ppm | 4M50G7D | 9 | 36, MO |
| 4945-4985 MHz | 0.41 | 1.6ppm | 9M01D7D | 9 | 36, MO |
| 4947.5-4982.5 MHz | 0.35 | 1.6ppm | 13M6D7D | 9 | 36, MO |
| 4950-4980 MHz | 0.35 | 1.6ppm | 18M1D7D | 9 | 36, MO |
| 5156.25-5247.5 MHz | 0.151 | 15E | 36, 38, MO | ||
| 5252.5-5345 MHz | 0.051 | 15E | 36, 38, MO, ND | ||
| 5475.75-5721.25 MHz | 0.049 | 15E | 36, 38, MO, ND | ||
| 5729-5846 MHz | 0.72 | 15E | 36, 48, MO |
Grants
TCB Grant - Application mk6WAF7xTeOrbnTv1uCCEQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 03/30/2017 Application Dated: 03/24/2017 |
| Cambium Networks Limited |
| Unit B2 Linhay Business Park |
| Eastern Road |
| Ashburton, Devon, TQ13 7UP United Kingdom |
| Attention: Don Reid , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWP-50670EX |
| Name of Grantee: | Cambium Networks Limited |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 MO | 90 | 4942.5 - 4987.5 | 0.42 | 1.6 PM | 4M50G7D |
| 36 MO | 90 | 4945.0 - 4985.0 | 0.41 | 1.6 PM | 9M01D7D |
| 36 MO | 90 | 4947.5 - 4982.5 | 0.35 | 1.6 PM | 13M6D7D |
| 36 MO | 90 | 4950.0 - 4980.0 | 0.35 | 1.6 PM | 18M1D7D |
| Output power is conducted. This device supports MIMO operations as described in this filing. The device supports 5MHz, 10MHz, 15MHz and 20MHz, bandwidths. Professional installation is required for devices with external antenna connectors. To comply with RF exposure requirements antennas must be installed to ensure a minimum separation distance of 2.07m from persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application mk6WAF7xTeOrbnTv1uCCEQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Cambium Networks Limited Unit B2 Linhay Business Park Eastern Road Ashburton, Devon, TQ13 7UP United Kingdom |
Date of Grant: 03/30/2017 Application Dated: 03/24/2017 |
| Attention: Don Reid , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWP-50670EX |
| Name of Grantee: | Cambium Networks Limited |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 MO | 90 | 4942.5 - 4987.5 | 0.42 | 1.6 PM | 4M50G7D |
| 36 MO | 90 | 4945.0 - 4985.0 | 0.41 | 1.6 PM | 9M01D7D |
| 36 MO | 90 | 4947.5 - 4982.5 | 0.35 | 1.6 PM | 13M6D7D |
| 36 MO | 90 | 4950.0 - 4980.0 | 0.35 | 1.6 PM | 18M1D7D |
| Output power is conducted. This device supports MIMO operations as described in this filing. The device supports 5MHz, 10MHz, 15MHz and 20MHz, bandwidths. Professional installation is required for devices with external antenna connectors. To comply with RF exposure requirements antennas must be installed to ensure a minimum separation distance of 2.07m from persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL International (UK) Ltd Unit 1 - 3 Horizon Kingsland Business Park Wade Road Basingstoke, RG24 8AH United Kingdom |
Date of Grant: 03/30/2017 Application Dated: 03/24/2017 |
| Cambium Networks Limited |
| Unit B2 Linhay Business Park |
| Eastern Road |
| Ashburton, Devon, TQ13 7UP United Kingdom |
| Attention: Don Reid , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWP-50670EX |
| Name of Grantee: | Cambium Networks Limited |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 38 MO | 15E | 5156.25 - 5247.5 | 0.151 | ||
| 36 38 MO ND | 15E | 5252.5 - 5345.0 | 0.051 | ||
| 36 38 MO ND | 15E | 5475.75 - 5721.25 | 0.049 | ||
| 36 48 MO | 15E | 5729.0 - 5846.0 | 0.72 |
| Output power is conducted. This device supports MIMO operations as described in this filing. The device supports 5 MHz, 10 MHz, 15 MHz, 20 MHz, 30 MHz, 40 MHz and 45 MHz bandwidths. Professional installation is required for devices with external antenna connectors. To comply with RF exposure requirements antennas must be installed to ensure a minimum separation distance of 0.61 m from persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. Class 3 Permissive Change to add U-NII-2A and U-NII-2C bands to the device. As detailed within C3PC filing dated 01/11/2016 for original FCC ID: QWP-45700. Class III Permissive Change to add UNII band 3 to ensure compliance to the updated U-NII rules (FCC R&O 14-30) as detailed within C3PC filing dated 03/09/2017 for original FCC ID: QWP-45700. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| 48: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains greater than 10 dBi and cannot be manufactured, marketed, sold or imported after March 2, 2018. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application 1sJkMcWXD/fgzxSLU/QDZQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Cambium Networks Limited Unit B2 Linhay Business Park Eastern Road Ashburton, Devon, TQ13 7UP United Kingdom |
Date of Grant: 03/30/2017 Application Dated: 03/24/2017 |
| Attention: Don Reid , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QWP-50670EX |
| Name of Grantee: | Cambium Networks Limited |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Ethernet Bridge Dual Channel OFDM MIMO Point to Point Equipment |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 36 38 MO | 15E | 5156.25 - 5247.5 | 0.151 | ||
| 36 38 MO ND | 15E | 5252.5 - 5345.0 | 0.051 | ||
| 36 38 MO ND | 15E | 5475.75 - 5721.25 | 0.049 | ||
| 36 48 MO | 15E | 5729.0 - 5846.0 | 0.72 |
| Output power is conducted. This device supports MIMO operations as described in this filing. The device supports 5 MHz, 10 MHz, 15 MHz, 20 MHz, 30 MHz, 40 MHz and 45 MHz bandwidths. Professional installation is required for devices with external antenna connectors. To comply with RF exposure requirements antennas must be installed to ensure a minimum separation distance of 0.61 m from persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. Class 3 Permissive Change to add U-NII-2A and U-NII-2C bands to the device. As detailed within C3PC filing dated 01/11/2016 for original FCC ID: QWP-45700. Class III Permissive Change to add UNII band 3 to ensure compliance to the updated U-NII rules (FCC R&O 14-30) as detailed within C3PC filing dated 03/09/2017 for original FCC ID: QWP-45700. |
| 36: | Certain antennas used with this equipment require a minimum cable length, or have output power limitations as documented in the application. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| 48: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains greater than 10 dBi and cannot be manufactured, marketed, sold or imported after March 2, 2018. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: |
