YL8860U Mobile Phone Test Setup Photos - FCC ID R38YL8860U

FCC ID R38YL8860U

test setup photo_PCE

Mobile Phone

by Yulong Computer Telecommunication Scientific (Shenzhen) Co. LTD

Document preview loads when visible.

Document Details

FCC IDR38YL8860U
Document ID2074145
Document TypeTest Setup Photos
Descriptiontest setup photo_PCE
Document TitleFG340403_R01_Part24E_Yulong_Coolpad 8860U_Appendix Ax
ApplicantYulong Computer Telecommunication Scientific (Shenzhen) Co. LTD
Equipment ClassMobile Phone
Product CodeYL8860U
Application IDMeETswV7GUNElWWu3eD13w==
Application PurposeOriginal Equipment
Application Date2013-09-18
Frequency Range1850.2-1909.8 MHz
FRN0022250344
Test FirmSPORTON INTERNATIONAL(KUN SHAN)INC.
Certified ByMichael Lin Vice President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/17/2014
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2013-09-17
Available2014-03-17
Created2013-09-11
Modified2013-09-11
Pages1
File TypeAdobe Acrobat PDF
File Size280700
File SHA-256df6c74f9be1a458edcbc1ff9986a2a94a689476c9d85db15893b7db6f3411f40
PDF Metadata AuthorSaraChen
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.4.5 (Windows)
FCC.gov SourcesFCC.gov 2074145
