2612J01 Walkie Talkie Block Diagram - FCC ID R4G2612J01

FCC ID R4G2612J01

Block Diagram

Walkie Talkie

by Joyo Electronics Company Limited

Document preview loads when visible.

Document Details

FCC IDR4G2612J01
Document ID1129086
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titleblock
ApplicantJoyo Electronics Company Limited
Equipment ClassWalkie Talkie
Product Code2612J01
Application IDXheVPRwIdR882F2FQgwYww==
Application PurposeOriginal Equipment
Application Date2009-06-24
Frequency Range49.86 MHz
FRN0004265807
Test FirmBay Area Compliance Laboratory Corp. (Shenzhen)
Certified ByAnita Fung
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2009-06-24
Available2009-06-24
Created2009-06-04
Modified2009-06-23
Pages1
File TypeAdobe Acrobat PDF
File Size17064
File SHA-2562e7e08f7f9761e78f2baab245ed6c2a0ddd54f95fc12cbf3ab6fe99957dd4b74
PDF Metadata AuthorAdministrator
PDF Metadata CreatorpdfFactory Pro www.fineprint.com.cn
PDF Metadata ProducerpdfFactory Pro 2.25 (Windows XP Chinese)
FCC.gov SourcesFCC.gov 1129086
