LXC940DF 19" LCD Monitor Block Diagram - FCC ID R95LXC940DF

FCC ID R95LXC940DF

Block Diagram

19" LCD Monitor

by ZHEJIANG XINGXING ELECTRONIC TECHNOLOGY AND DEVELOPMENT CO., LTD.

Document preview loads when visible.

Document Details

FCC IDR95LXC940DF
Document ID477753
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleB-Diagram_940DF_
ApplicantZHEJIANG XINGXING ELECTRONIC TECHNOLOGY AND DEVELOPMENT CO., LTD.
Equipment Class19" LCD Monitor
Product CodeLXC940DF
Application IDhEIyoGA6JKQrplMdPymogQ==
Application PurposeOriginal Equipment
Application Date2004-10-11
FRN0019505932
Test FirmIST Co., Ltd.
Certified ByH.C. Kim Manager (Agent)
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-10-11
Available2004-10-11
Created2004-10-07
Modified2004-10-07
Pages1
File TypeAdobe Acrobat PDF
File Size75599
File SHA-256a4fa408f240be6bb25073df76530b936ea403d95e74958f9ab4e0e73ef7f6bcd
PDF Metadata Author<B1E8BCF6BECF>
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows) <B1E8BCF6BECF>
FCC.gov SourcesFCC.gov 477753
