88C613000500 Turbo RC Pro Schematics - FCC ID R9P88C613000500

FCC ID R9P88C613000500

circuit diagram

Turbo RC Pro

by Meccano (Hong Kong) Limited

Document preview loads when visible.

Document Details

FCC IDR9P88C613000500
Document ID1488434
Document TypeSchematics
Descriptioncircuit diagram
Document TitleTX CIRCUIT DIAGRAM For 27MHZ Turbo RC Pro
ApplicantMeccano (Hong Kong) Limited
Equipment ClassTurbo RC Pro
Product Code88C613000500
Application IDhf+aPBbAXmZ2fWDgX6ZkCw==
Application PurposeOriginal Equipment
Application Date2011-06-22
Frequency Range27.145 MHz
FRN0019285121
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByTerry Chan Assistant Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2011-06-22
Available2011-06-22
Created2011-05-28
Modified2011-06-14
Pages1
File TypeAdobe Acrobat PDF
File Size482768
File SHA-256adfcfa5c7b7cd2b01d558f4501bdb777202bda081047211b119a5aa936c869ff
PDF Metadata Authorlgw
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 1488434
