7221 BLUETOOTH USB DONGLE Schematics - FCC ID RAJ7221
FCC ID RAJ7221
CIRCUIT DIAGRAM
BLUETOOTH USB DONGLE
Document preview loads when visible.
Document Details
| FCC ID | RAJ7221 |
|---|---|
| Document ID | 357027 |
| Document Type | Schematics |
| Description | CIRCUIT DIAGRAM |
| Document Title | SCHEMATIC1 : BTUSB01 |
| Applicant | TAIWAN FIRST LINE ELECTRONICS CORP. |
| Equipment Class | BLUETOOTH USB DONGLE |
| Product Code | 7221 |
| Application ID | o45hI2bFXGjwh2d6qB0xpg== |
| Application Purpose | Original Equipment |
| Application Date | 2003-09-15 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0009178542 |
| Test Firm | Spectrum Research & Testing Lab. |
| Certified By | TIM YEN R&D; MANAGER |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-09-15 |
| Available | 2003-09-15 |
| Created | 2002-05-20 |
| Modified | 2002-05-20 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 10522 |
| File SHA-256 | 6db6dc6c2e29c2829d9860e45be5e881cdf358b91965c12df78ed8fe2b8a5c79 |
| PDF Metadata Author | PDFDriver 劉茂松 |
| PDF Metadata Producer | SCHEMATIC1 : BTUSB01 DocuCom PDF Driver 4.0 |
| FCC.gov Sources | FCC.gov 357027 |
