FCC ID RAX-AIOS4-0F
HEOS 4.X Platform Module
by Arcadyan Technology Corporation
Grantee Code: RAX Product Code: AIOS40F
Latest application date: 2020-01-16
Device Images
FCC ID Device Details
| FCC ID | RAX-AIOS4-0F |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RAX |
| Product Code | AIOS40F |
| Applicant Business | Arcadyan Technology Corporation 🇹🇼 |
| Related Domains |  arcadyan.com |
| Equipment Class | HEOS 4.X Platform Module |
| Test Firm | Sporton International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2020-01-16 |
| 5180-5240 MHz | Original Equipment | 2015-10-14 |
| 2402-2480 MHz | Original Equipment | 2015-10-14 |
| 2402-2480 MHz | Original Equipment | 2015-10-14 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| OEM Manual | Users Manual | 2015-10-14 | PDF 428.4 KB |
| User Manual | Users Manual | 2015-10-14 | PDF 391.5 KB |
| Internal Photos | Internal Photos | 2015-10-14 | PDF 927.7 KB |
| External Photos | External Photos | 2015-10-14 | PDF 697.6 KB |
| Label & Label Location | ID Label/Location Info | 2015-10-14 | PDF 941.8 KB |
| DFS TEST PHOTOS | Test Setup Photos | 2020-01-16 | PDF 145.5 KB |
| RF Test Photos | Test Setup Photos | 2020-01-16 | PDF 493 KB |
| Test Setup Photos DFS | Test Setup Photos | 2015-10-14 | PDF 108 KB |
| Test Setup Photos DTS 2.4G | Test Setup Photos | 2015-10-14 | PDF 582.4 KB |
| Test Setup Photos DTS BT 4.0 | Test Setup Photos | 2015-10-14 | PDF 582.7 KB |
| DFS test report | Test Report | 2020-01-16 | PDF 996.1 KB |
| MPE test report | RF Exposure Info | 2020-01-16 | PDF 221.9 KB |
| RF test report | Test Report | 2020-01-16 | PDF 4.5 MB |
| Radiated Emission Co Location Report | Test Report | 2015-10-14 | PDF 136.9 KB |
| Test Report DFS | Test Report | 2015-10-14 | PDF 508.1 KB |
| Test Report DSS | Test Report | 2015-10-14 | PDF 2.2 MB |
| Test Report DTS 2.4G | Test Report | 2015-10-14 | PDF 2.2 MB |
| Test Report DTS BT 4.0 | Test Report | 2015-10-14 | PDF 866.1 KB |
| Test Report NII Part 1 | Test Report | 2015-10-14 | PDF 4.3 MB |
| Test Report NII Part 2 | Test Report | 2015-10-14 | PDF 5 MB |
| C2PC letter | Cover Letter(s) | 2020-01-16 | PDF 213.7 KB |
| Confidential letter | Cover Letter(s) | 2020-01-16 | PDF 218.1 KB |
| POA | Cover Letter(s) | 2020-01-16 | PDF 214.1 KB |
| TPC declaration letter | Cover Letter(s) | 2020-01-16 | PDF 216 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-10-14 | PDF 20.1 KB |
| DOC Letter | Cover Letter(s) | 2015-10-14 | PDF 18.2 KB |
| Declaration Letter | Cover Letter(s) | 2015-10-14 | PDF 19.4 KB |
| DoC Letter | Cover Letter(s) | 2015-10-14 | PDF 18.2 KB |
| Modular Approval Letter | Cover Letter(s) | 2015-10-14 | PDF 26 KB |
| POA | Cover Letter(s) | 2015-10-14 | PDF 18.3 KB |
| Human Exposure | RF Exposure Info | 2015-10-14 | PDF 230.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 85.1 KB | |
| Schematics Metadata only | Schematics | PDF 497.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 93.6 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 31.6 KB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 128.1 KB |
Application Information
| Application ID | 3T3M8LenxpTN+Isr3CuTjg== |
|---|---|
| Final Action Date | 2020-01-16 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0009258708 |
| Model | AIOS4-0F |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | HEOS 4.X Platform Module |
| Responsible Party | Simon Liu, Manager, simon_liu@arcadyan.com , 886-3-572-7000 |
| Test Firm | Alex CHEN, Sporton International Inc., alex@sporton.com.tw  , +886-3-327-3456 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4GHz and 5GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 3T3M8LenxpTN+Isr3CuTjg== | 2020-01-16 | Class II permissive change or modification of presently authorized equipment |
| xJtbm5ZeZaKqJzdsBtqegQ== | 2015-10-14 | Original Equipment |
| c+4E884+ZvSapo/ek7vfgw== | 2015-10-14 | Original Equipment |
| 54EUT55xGGF187nlwPu6IA== | 2015-10-14 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 2402-2480 MHz | 0.0070000 | 15C | CC |
| 2402-2480 MHz | 0.003 | 15C | CC |
| 2412-2462 MHz | 0.149 | 15C | CC, MO |
| 5180-5240 MHz | 0.243 | 15E | CC, MO |
| 5180-5240 MHz | 0.243 | 15E | 38, CC, MO |
| 5260-5320 MHz | 0.223 | 15E | CC, MO |
| 5260-5320 MHz | 0.223 | 15E | 38, CC, MO |
| 5500-5720 MHz | 0.221 | 15E | CC, MO |
| 5500-5720 MHz | 0.221 | 15E | 38, CC, MO |
| 5745-5825 MHz | 0.307 | 15E | CC, MO |
| 5745-5825 MHz | 0.307 | 15E | 38, CC, MO |
Grants
TCB Grant - Application xJtbm5ZeZaKqJzdsBtqegQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Arcadyan Technology Corporation |
| No.8, Sec.2, Guangfu Rd., |
| Hsinchu, 30071 Taiwan |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.243 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.223 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.221 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.307 |
| Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application xJtbm5ZeZaKqJzdsBtqegQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Arcadyan Technology Corporation No.8, Sec.2, Guangfu Rd., Hsinchu, 30071 Taiwan |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.243 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.223 | ||
| 38 CC MO | 15E | 5500.0 - 5720.0 | 0.221 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.307 |
| Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Arcadyan Technology Corporation |
| No.8, Sec.2, Guangfu Rd., |
| Hsinchu, 30071 Taiwan |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.007 |
| Single Modular Approval. Power listed is conducted. This device is restricted to fixed indoor and mobile use only. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application c+4E884+ZvSapo/ek7vfgw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Arcadyan Technology Corporation No.8, Sec.2, Guangfu Rd., Hsinchu, 30071 Taiwan |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.007 |
| Single Modular Approval. Power listed is conducted. This device is restricted to fixed indoor and mobile use only. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Arcadyan Technology Corporation |
| No.8, Sec.2, Guangfu Rd., |
| Hsinchu, 30071 Taiwan |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.149 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.003 |
| Single Modular Approval. Power listed is maximum combined conducted output power in 802.11bgn mode and maximum conducted output power for BT4.0 mode. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 54EUT55xGGF187nlwPu6IA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Arcadyan Technology Corporation No.8, Sec.2, Guangfu Rd., Hsinchu, 30071 Taiwan |
Date of Grant: 10/14/2015 Application Dated: 10/13/2015 |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.149 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.003 |
| Single Modular Approval. Power listed is maximum combined conducted output power in 802.11bgn mode and maximum conducted output power for BT4.0 mode. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 01/16/2020 Application Dated: 12/06/2019 |
| Arcadyan Technology Corporation |
| No.8, Sec.2, Guangfu Rd., |
| Hsinchu, 30071 Taiwan |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.243 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.223 | ||
| CC MO | 15E | 5500.0 - 5720.0 | 0.221 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.307 |
| Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4GHz and 5GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 3T3M8LenxpTN+Isr3CuTjg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Arcadyan Technology Corporation No.8, Sec.2, Guangfu Rd., Hsinchu, 30071 Taiwan |
Date of Grant: 01/16/2020 Application Dated: 12/06/2019 |
| Attention: Simon Liu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RAX-AIOS4-0F |
| Name of Grantee: | Arcadyan Technology Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | HEOS 4.X Platform Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.243 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.223 | ||
| CC MO | 15E | 5500.0 - 5720.0 | 0.221 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.307 |
| Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4GHz and 5GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz, 40 MHz, and 80 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
