FCC ID RAX-AIOS4-0S
HEOS 4.X Platform Module
by Arcadyan Technology Corporation
Grantee Code: RAX Product Code: AIOS40S
Latest application date: 2015-10-14
Device Images
FCC ID Device Details
| FCC ID | RAX-AIOS4-0S |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RAX |
| Product Code | AIOS40S |
| Applicant Business | Arcadyan Technology Corporation 🇹🇼 |
| Related Domains |  arcadyan.com |
| Equipment Class | HEOS 4.X Platform Module |
| Test Firm | Sporton International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-14 |
| 5180-5240 MHz | Original Equipment | 2015-10-14 |
| 2402-2480 MHz | Original Equipment | 2015-10-14 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| OEM Manual | Users Manual | 2015-10-14 | PDF 371.8 KB |
| User Manual | Users Manual | 2015-10-14 | PDF 391.5 KB |
| Internal Photos | Internal Photos | 2015-10-14 | PDF 803.6 KB |
| External Photos | External Photos | 2015-10-14 | PDF 564.9 KB |
| Label & Label Location | ID Label/Location Info | 2015-10-14 | PDF 941.9 KB |
| Label and Label Location | ID Label/Location Info | 2015-10-14 | PDF 941.9 KB |
| Test Setup Photos DFS | Test Setup Photos | 2015-10-14 | PDF 107.6 KB |
| Test Setup Photos DSS | Test Setup Photos | 2015-10-14 | PDF 485.7 KB |
| Test Setup Photos DTS | Test Setup Photos | 2015-10-14 | PDF 485.5 KB |
| Test Setup Photos NII | Test Setup Photos | 2015-10-14 | PDF 485.7 KB |
| Radiated Emission Co Location Report | Test Report | 2015-10-14 | PDF 136.6 KB |
| Test Report DFS | Test Report | 2015-10-14 | PDF 509 KB |
| Test Report DSS | Test Report | 2015-10-14 | PDF 2.1 MB |
| Test Report DTS 2.4G | Test Report | 2015-10-14 | PDF 2.1 MB |
| Test Report DTS BT 4.0 | Test Report | 2015-10-14 | PDF 840.4 KB |
| Test Report NII Part 1 | Test Report | 2015-10-14 | PDF 4.8 MB |
| Test Report NII Part 2 | Test Report | 2015-10-14 | PDF 3.7 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-10-14 | PDF 20.2 KB |
| Declaration Letter | Cover Letter(s) | 2015-10-14 | PDF 19.6 KB |
| Modular Approval Letter | Cover Letter(s) | 2015-10-14 | PDF 25.9 KB |
| POA | Cover Letter(s) | 2015-10-14 | PDF 18.4 KB |
| Human Exposure | RF Exposure Info | 2015-10-14 | PDF 223.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 85.1 KB | |
| Schematics Metadata only | Schematics | PDF 497.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 92.5 KB | |
| Operational Description Software Security Metadata only | Operational Description | PDF 31.3 KB |
Application Information
| Application ID | iqCcWx5YkN+wN3XNkvFGWA== |
|---|---|
| Final Action Date | 2015-10-14 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009258708 |
| Model | AIOS4-0S |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | HEOS 4.X Platform Module |
| Responsible Party | Simon Liu, Manager, simon_liu@arcadyan.com , 886-3-572-7000 |
| Test Firm | Alex Chen, Sporton International Inc., alex@sporton.com.tw  , 886-3-327-3456 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power in 802.11bgn mode and maximum conducted output power for BT4.0 mode. This device isThis device is restricted to fixed indoor and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. The antenna(s) used for this transmitter must not exceed a maximum gain of 3.1 dBi and 3.66 dBi in 2.4 GHz and 5.2 GHz band, respectively. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
