FCC ID RAXHT2000W
HT2000W wifi module
by Arcadyan Technology Corporation
Grantee Code: RAX Product Code: HT2000W
Latest application date: 2016-10-11
Device Images
FCC ID Device Details
| FCC ID | RAXHT2000W |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RAX |
| Product Code | HT2000W |
| Applicant Business | Arcadyan Technology Corporation 🇹🇼 |
| Related Domains |  arcadyan.com |
| Equipment Class | HT2000W wifi module |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-11 |
| 5180-5240 MHz | Original Equipment | 2016-10-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Front-End Module User Manual | Users Manual | 2016-10-11 | PDF 491 KB |
| High Power Wireless LAN Power Amplifier User Manual | Users Manual | 2016-10-11 | PDF 366.6 KB |
| Module Installation Instruction User Manual | Users Manual | 2016-10-11 | PDF 1.5 MB |
| User Manual Blocked | Users Manual | 2016-10-11 | PDF 1.4 MB |
| User Manual 2016 Blocked | Users Manual | 2016-10-11 | PDF 1.4 MB |
| Users Manual | Users Manual | 2016-10-11 | PDF 159.5 KB |
| Internal Photo Host | Internal Photos | 2016-10-11 | PDF 161.4 KB |
| Internal Photos | Internal Photos | 2016-10-11 | PDF 216.8 KB |
| External Photo | External Photos | 2016-10-11 | PDF 169.7 KB |
| External Photo Host | External Photos | 2016-10-11 | PDF 169.7 KB |
| External Photos | External Photos | 2016-10-11 | PDF 2.2 MB |
| Label and Location | ID Label/Location Info | 2016-10-11 | PDF 433.3 KB |
| Test Photos | Test Setup Photos | 2016-10-11 | PDF 282.7 KB |
| MPE Test Report | RF Exposure Info | 2016-10-11 | PDF 362.6 KB |
| Test Report | Test Report | 2016-10-11 | PDF 4.3 MB |
| Test Report | Test Report | 2016-10-11 | PDF 3.8 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-10-11 | PDF 62.5 KB |
| Limited Module Approval Request Letter | Cover Letter(s) | 2016-10-11 | PDF 16.8 KB |
| POA | Cover Letter(s) | 2016-10-11 | PDF 60 KB |
| MPE Test | RF Exposure Info | 2016-10-11 | PDF 362.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 16.6 KB | |
| Schematics Metadata only | Schematics | PDF 551 KB | |
| Operational Description Metadata only | Operational Description | PDF 86.3 KB | |
| Operational Description SW Security Metadata only | SDR Software/Security Inf | PDF 40.9 KB |
Application Information
| Application ID | z4NJOsEM24/jORCP3GExrQ== |
|---|---|
| Final Action Date | 2016-10-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009258708 |
| Model | HT2000W |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | HT2000W wifi module |
| Responsible Party | Simon Liu, Manager, simon_liu@arcadyan.com , 886-3-572-7000 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The EUT is a limited module, which is only limited to the host (brand: HUGHES / model: HT2000W). The antennas used for this transmitter must be installed with the antenna provided, must provide a separation distance of at least 20 cm from all persons, and must not be co-located or operating in conjunction with any other antenna or transmitter. This module is restricted to mobile and fixed applications. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. Users and installers must be provided with device operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. |
