BTM010 SkyRC Bluetooth Module Test Setup Photos - FCC ID REY-BTM010
FCC ID REY-BTM010
Test setup photos
SkyRC Bluetooth Module
Document preview loads when visible.
Document Details
| FCC ID | REY-BTM010 |
|---|---|
| Document ID | 4145491 |
| Document Type | Test Setup Photos |
| Description | Test setup photos |
| Document Title | Measurement Report |
| Applicant | SKYRC Technology Co., Ltd. |
| Equipment Class | SkyRC Bluetooth Module |
| Product Code | BTM010 |
| Application ID | yiWA1FYi56jaGHcvBe+rgg== |
| Application Purpose | Original Equipment |
| Application Date | 2019-01-25 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0022257208 |
| Test Firm | Shenzhen CTL Testing Technology Co., Ltd. |
| Certified By | Rui Zou Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-01-25 |
| Available | 2019-01-25 |
| Created | 2011-12-09 |
| Modified | 2019-01-24 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 180352 |
| File SHA-256 | f37afc0f3d32efbbeb6e8bb036c26e34ed5d68acff445702c84f1397aad54e40 |
| PDF Metadata Author | Kent |
| PDF Metadata Producer | Kent Aspose.Words for .NET 16.7.0.0 |
| FCC.gov Sources | FCC.gov 4145491 |
