Industrial Wireless System
Document preview loads when visible.
Document Details
| FCC ID | RF41689B |
|---|---|
| Document ID | 7078957 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Keyence Corporation |
| Equipment Class | Industrial Wireless System |
| Product Code | 1689B |
| Application ID | S4fXY6i6aP1tETzvUGzt7A== |
| Application Purpose | Original Equipment |
| Application Date | 2024-03-04 |
| Frequency Range | 5955-7115 MHz |
| FRN | 0009419870 |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch Hsin |
| Certified By | Trista Tsai Specialist |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 08/31/2024 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2024-01-25 |
| Available | 2024-08-31 |
| Created | 2023-06-20 |
| Modified | 2023-06-30 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 1582516 |
| File SHA-256 | bd675f4d8412521bacf6b8b48e3c9ee0c7ce99f59af3f894cc22e2e8eaab6ae6 |
| PDF Metadata Author | Phoenix HUANG |
| PDF Metadata Producer | Phoenix HUANG Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 7078957, FCC.gov 7078929 |
