OM12030100 2G/3.5G wireless module Test... - FCC ID RI7OM12030-100

FCC ID RI7OM12030-100

Test setup photos

2G/3.5G wireless module

by Telit Communications S.p.A.

Document preview loads when visible.

Document Details

FCC IDRI7OM12030-100
Document ID2559664
Document TypeTest Setup Photos
DescriptionTest setup photos
Document Title42853RRF001_Photographs
ApplicantTelit Communications S.p.A.
Equipment Class2G/3.5G wireless module
Product CodeOM12030100
Application IDsdmqYExZL8PwX+KWh3VGpw==
Application PurposeOriginal Equipment
Application Date2015-03-19
Frequency Range1850.2-1909.8 MHz
FRN0020384608
Test FirmDEKRA Testing and Certification, S.A.U.
Certified ByBrian Tucker Global VP, Quality
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/15/2015
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2015-03-19
Available2015-09-15
Created2015-02-18
Modified2015-02-18
Pages6
File TypeAdobe Acrobat PDF
File Size724856
File SHA-256141e08d94ea3ebed5a9da24d0b1cf32181a18bbecf1ed580d5ad1f799655dbfd
PDF Metadata AuthorALL
PDF Metadata ProducerGPL Ghostscript 9.04 ALL
FCC.gov SourcesFCC.gov 2559664
