TUPDJN3980027 RC Car Block Diagram - FCC ID RJ2TUPDJN-3980027

FCC ID RJ2TUPDJN-3980027

Block Diagram

RC Car

by Team Up Product Dev. Co. Ltd.

Document preview loads when visible.

Document Details

FCC IDRJ2TUPDJN-3980027
Document ID462065
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantTeam Up Product Dev. Co. Ltd.
Equipment ClassRC Car
Product CodeTUPDJN3980027
Application IDwCj+K6ZgdVFSSFWL01GFBg==
Application PurposeOriginal Equipment
Application Date2004-08-21
Frequency Range27.145 MHz
FRN0003786449
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-08-21
Available2004-08-21
Created2004-07-30
Modified2004-08-03
Pages1
File TypeAdobe Acrobat PDF
File Size23689
File SHA-2565ede601bb56c8d23b4d8545c451484de07df52b43f3fbc8372289352baacf23c
PDF Metadata AuthorITS ELECTRIC TOY
PDF Metadata ProducerHP 9100C Digital Sender
FCC.gov SourcesFCC.gov 462065
