DBL Smart Video Doorbell Teardown Internal Photos - FCC ID RJY-DBL
FCC ID RJY-DBL
Int Photos
Smart Video Doorbell
Document preview loads when visible.
Document Details
| FCC ID | RJY-DBL |
|---|---|
| Document ID | 3838269 |
| Document Type | Internal Photos |
| Description | Int Photos |
| Document Title | Internal Photos-----0 |
| Applicant | Chuango Security Technology Corporation |
| Equipment Class | Smart Video Doorbell |
| Product Code | DBL |
| Application ID | SBcfEtraLb8WsfGoElKyuA== |
| Application Purpose | Original Equipment |
| Application Date | 2018-05-03 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0022290779 |
| Test Firm | Bay Area Compliance Laboratories Corp. (Shenzhen) |
| Certified By | Ken Li |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2018-05-03 |
| Available | 2018-05-03 |
| Created | 2018-04-27 |
| Modified | 2018-04-27 |
| Pages | 10 |
| File Type | Adobe Acrobat PDF |
| File Size | 1862190 |
| File SHA-256 | bcda927fb4e14e822713bfee71f07d7c03933cb9fbda30a280f7e6693284e6dc |
| PDF Metadata Author | SZ076 |
| PDF Metadata Producer | SZ076 Acrobat Distiller 9.0.0 (Windows) |
| FCC.gov Sources | FCC.gov 3838269, FCC.gov 3838256 |
