ASW2301 ASTARTE / SOFTGATE Block Diagram - FCC ID ROL-ASW2301

FCC ID ROL-ASW2301

BLOCK DIAGRAM

ASTARTE / SOFTGATE

by Astarte Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDROL-ASW2301
Document ID386011
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
ApplicantAstarte Technology Co., Ltd.
Equipment ClassASTARTE / SOFTGATE
Product CodeASW2301
Application IDRHJSV5/x3p9LfXC6C14XJA==
Application PurposeOriginal Equipment
Application Date2004-01-05
Frequency Range2412-2462 MHz
FRN0009945841
Test FirmSporton International Inc.
Certified ByJAMES YANG MARKETING MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-01-05
Available2004-01-05
Created2003-12-08
Modified2003-12-08
Pages1
File TypeAdobe Acrobat PDF
File Size8183
File SHA-25699a2b59c8d672dbbe6a78aaac47e5efb9c214b8e013ff89b046545b824c4fe7a
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows)
FCC.gov SourcesFCC.gov 386011
