TQM6403GEN2 IEEE802.11ax tri-radio... - FCC ID RSL-TQM6403GEN2
FCC ID RSL-TQM6403GEN2
RF Test Photos
IEEE802.11ax tri-radio 5G/5G/2.4GHz 2x2+2x2+2x2 wireless AP
Document preview loads when visible.
Document Details
| FCC ID | RSL-TQM6403GEN2 |
|---|---|
| Document ID | 6260792 |
| Document Type | Test Setup Photos |
| Description | RF Test Photos |
| Applicant | Allied Telesis K.K. |
| Equipment Class | IEEE802.11ax tri-radio 5G/5G/2.4GHz 2x2+2x2+2x2 wireless AP |
| Product Code | TQM6403GEN2 |
| Application ID | i/rTeGSNXmeb4beqTgHUUA== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2022-12-13 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0009668120 |
| Test Firm | Sporton International Inc. Hsinchu Laboratory |
| Certified By | Leo Huang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 06/11/2023 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-12-06 |
| Available | 2023-06-11 |
| Created | 2022-12-02 |
| Modified | 2022-12-02 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 239996 |
| File SHA-256 | e95b3a87ddcaa49fe33b9adc907b21a8ff9a876e2bf271e64eb8b614d4768e7e |
| PDF Metadata Author | Bunny |
| PDF Metadata Producer | Bunny Adobe PDF Library 15.0 |
| FCC.gov Sources | FCC.gov 6260792 |
