RFS2 RFS Transceiver Module Teardown Internal... - FCC ID RW3RFS2

FCC ID RW3RFS2

Internal Photos

RFS Transceiver Module

by Bron Elektronik AG

Document preview loads when visible.

Document Details

FCC IDRW3RFS2
Document ID428658
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleAnnex No 2_01
ApplicantBron Elektronik AG
Equipment ClassRFS Transceiver Module
Product CodeRFS2
Application IDN9bUTtYXIGfsEeV7ICLP2w==
Application PurposeOriginal Equipment
Application Date2004-06-07
Frequency Range914 MHz
FRN0026655266
Test Firmm. dudde hochfrequenz-technik
Certified ByMr. Ralf Trepper Technical engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2004-06-07
Available2004-06-07
Created2004-04-14
Modified2004-04-14
Pages6
File TypeAdobe Acrobat PDF
File Size839562
File SHA-25645c3ef4fab36f4c3c0c890f2a90801ebbca3ff3b7e1a693bb28f39c61a42fc51
PDF Metadata AuthorManfried Dudde
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows) Manfried Dudde
FCC.gov SourcesFCC.gov 428658
