FCC ID RX3-WBUA31
Dual-Band 2x2 802.11ac and BT4.1 Combo Module
by Hon Hai Precision Industry Co., Ltd.
Grantee Code: RX3 Product Code: WBUA31
Latest application date: 2016-09-02
Device Images
FCC ID Device Details
| FCC ID | RX3-WBUA31 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RX3 |
| Product Code | WBUA31 |
| Applicant Business | Hon Hai Precision Industry Co., Ltd. 🇹🇼 |
| Related Domains |  foxconn.com  sgs.com |
| Equipment Class | Dual-Band 2x2 802.11ac and BT4.1 Combo Module |
| Test Firm | SGS Taiwan Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-09-02 |
| 2402-2480 MHz | Original Equipment | 2016-09-02 |
| 2402-2480 MHz | Original Equipment | 2016-09-02 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-09-02 | PDF 1.1 MB |
| Internal Photos | Internal Photos | 2016-09-02 | PDF 103.4 KB |
| External Photos | External Photos | 2016-09-02 | PDF 111.2 KB |
| ID Label/Location Info | ID Label/Location Info | 2016-09-02 | PDF 320 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-02 | PDF 1.1 MB |
| DSS test report_BT FHSS | Test Report | 2016-09-02 | PDF 4.3 MB |
| DTS test report_802.11 | Test Report | 2016-09-02 | PDF 3.5 MB |
| DTS test report_BT LE | Test Report | 2016-09-02 | PDF 2.2 MB |
| ER-2016-80010_P15.247+RSS247 WLAN_MIMO Report | Test Report | 2016-09-02 | PDF 3.1 MB |
| ER-2016-80011_P15.247RSS247 BLE Report | Test Report | 2016-09-02 | PDF 2.1 MB |
| ER-2016-80013_P15.407RSS247 UNII _MIMO Report | Test Report | 2016-09-02 | PDF 5.6 MB |
| ER-2016-80014_P15.407RSS247 DFS Report | Test Report | 2016-09-02 | PDF 793.1 KB |
| Test Report_DSS | Test Report | 2016-09-02 | PDF 1.8 MB |
| UNII test report | Test Report | 2016-09-02 | PDF 5.4 MB |
| UNII test report Part III | Test Report | 2016-09-02 | PDF 1.2 MB |
| UNII test report part II | Test Report | 2016-09-02 | PDF 5.5 MB |
| Declaration Letter | Cover Letter(s) | 2016-09-02 | PDF 24.5 KB |
| Declaration Letter - DoC | Cover Letter(s) | 2016-09-02 | PDF 24.5 KB |
| Declaration of authorization | Cover Letter(s) | 2016-09-02 | PDF 113.8 KB |
| Declaration of authorization.doc | Cover Letter(s) | 2016-09-02 | PDF 113.8 KB |
| DeclarationLetter | Cover Letter(s) | 2016-09-02 | PDF 292.8 KB |
| FCC Modular Approval Request | Cover Letter(s) | 2016-09-02 | PDF 191.2 KB |
| The justification letter of supersede | Cover Letter(s) | 2016-09-02 | PDF 258.6 KB |
| The justification letter of superseding | Cover Letter(s) | 2016-09-02 | PDF 258.6 KB |
| confidentiality FC | Cover Letter(s) | 2016-09-02 | PDF 498 KB |
| Collocated MPE Analysis | RF Exposure Info | 2016-09-02 | PDF 173.1 KB |
| ER-2016-80010_MPE FCC | RF Exposure Info | 2016-09-02 | PDF 172 KB |
| ER-2016-80011_MPE FCC | RF Exposure Info | 2016-09-02 | PDF 156.6 KB |
| ER-2016-80013_MPE FCC | RF Exposure Info | 2016-09-02 | PDF 207.4 KB |
| MPE | RF Exposure Info | 2016-09-02 | PDF 155.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 88.6 KB | |
| Schematics Metadata only | Schematics | PDF 202.3 KB | |
| DFS client device channel plan and software operational declaration Metadata only | Operational Description | PDF 263.6 KB | |
| NII Software Security Info Metadata only | Operational Description | PDF 406.9 KB | |
| Operation Desription_Antenna report Metadata only | Operational Description | PDF 2 MB | |
| Operational Description Metadata only | Operational Description | PDF 159.5 KB |
Application Information
| Application ID | xljQxCa0Cb6N/Xk8e2Xb9w== |
|---|---|
| Final Action Date | 2016-09-02 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022375083 |
| Model | WBUA31 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Dual-Band 2x2 802.11ac and BT4.1 Combo Module |
| Responsible Party | Cathy Kuo, cathy.cj.kuo@foxconn.com , +886-2-2268-3466 |
| Technical Contact | Willis Chen, SGS Taiwan Ltd., willis.chen@sgs.com , 886222993279 |
| Non-Technical Contact | Willis Chen, SGS Taiwan Ltd., willis.chen@sgs.com , 886222993279 |
| Test Firm | Ryan Wang, SGS Taiwan Ltd., Ryan-ec.wang@sgs.com , +886-2-2299-3279 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidths. The 80 MHz mode is limited to channel at 5290MHz, 5530MHz, 5690MHz, 5610MHz, and 5775 MHz |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| xljQxCa0Cb6N/Xk8e2Xb9w== | 2016-09-02 | Original Equipment |
| rGG4PWpyxGEnjXahQI8xOQ== | 2016-09-02 | Original Equipment |
| 7rGr5taUH7GCUBeInLdYYQ== | 2016-09-02 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application xljQxCa0Cb6N/Xk8e2Xb9w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 09/02/2016 Application Dated: 09/01/2016 |
| Hon Hai Precision Industry Co., Ltd. |
| No.151, Sec. 1, Nankan Rd., Lujhu Dist., |
| Taoyuan City, 33859 Taiwan |
| Attention: Cathy Kuo |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RX3-WBUA31 |
| Name of Grantee: | Hon Hai Precision Industry Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Dual-Band 2x2 802.11ac and BT4.1 Combo Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.025 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.024 | ||
| 38 CC MO ND | 15E | 5500.0 - 5700.0 | 0.024 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.025 |
| Single Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. End-users may not be provided with the module installation instructions. OEM integrators and end-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidths. The 80 MHz mode is limited to channel at 5290MHz, 5530MHz, 5690MHz, 5610MHz, and 5775 MHz |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
