WBU053VZBT 802.11a/b/g/n/ 2T2R with... - FCC ID RX3-WBU053VZBT
FCC ID RX3-WBU053VZBT
DFS Test set-up photo
802.11a/b/g/n/ 2T2R with Bluetooth combo wireless module
Document preview loads when visible.
Document Details
| FCC ID | RX3-WBU053VZBT |
|---|---|
| Document ID | 5009699 |
| Document Type | Test Setup Photos |
| Description | DFS Test set-up photo |
| Document Title | RFBGTL-WTW-P20100273-2 (TSup Photo for FCC DFS) |
| Applicant | Hon Hai Precision Industry Co., Ltd. |
| Equipment Class | 802.11a/b/g/n/ 2T2R with Bluetooth combo wireless module |
| Product Code | WBU053VZBT |
| Application ID | ep+3YKNdG1RZBSvzdrsppA== |
| Application Purpose | Original Equipment |
| Application Date | 2020-11-24 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0022375083 |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch |
| Certified By | Debby Lin |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2020-11-23 |
| Available | 2020-11-24 |
| Created | 2020-11-19 |
| Modified | 2020-11-19 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 125204 |
| File SHA-256 | 0ade3c1d88e5dde9c1c0f515e4bb0dc341c3471e8c0e65416b4e9d9fcfaf2708 |
| PDF Metadata Author | pochien |
| PDF Metadata Producer | pochien Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 5009699 |
