FCC ID RYK-WUBR508N
802.11abgn, USB module
by SparkLAN Communications, Inc.
Grantee Code: RYK Product Code: WUBR508N
Latest application date: 2020-07-29
Device Images
FCC ID Device Details
| FCC ID | RYK-WUBR508N |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RYK |
| Product Code | WUBR508N |
| Applicant Business | SparkLAN Communications, Inc. 🇹🇼 |
| Related Domains |  sparklan.com |
| Equipment Class | 802.11abgn, USB module |
| Test Firm | MRT Technology (Suzhou) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2020-07-29 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2020-07-29 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2020-03-11 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2020-03-11 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-06-24 |
| 2412-2462 MHz | Original Equipment | 2012-06-11 |
| 5180-5240 MHz | Original Equipment | 2012-06-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2020-07-29 | PDF 2.3 MB |
| Users Manual | Users Manual | 2020-03-11 | PDF 4 MB |
| user manual | Users Manual | 2012-06-11 | PDF 601.1 KB |
| Internal Photos | Internal Photos | 2020-07-29 | PDF 4.3 MB |
| Internal Report | Internal Photos | 2020-07-29 | PDF 4.3 MB |
| Internal Photos | Internal Photos | 2020-03-11 | PDF 618.4 KB |
| Int Photos diople I | Internal Photos | 2012-06-11 | PDF 2.6 MB |
| Int Photos diople II | Internal Photos | 2012-06-11 | PDF 2.7 MB |
| Int Photos printed | Internal Photos | 2012-06-11 | PDF 4.2 MB |
| int photos diople I | Internal Photos | 2012-06-11 | PDF 2.6 MB |
| int photos diople II | Internal Photos | 2012-06-11 | PDF 2.7 MB |
| int photos printed | Internal Photos | 2012-06-11 | PDF 4.2 MB |
| External Photos | External Photos | 2020-07-29 | PDF 496.1 KB |
| External Report | External Photos | 2020-07-29 | PDF 496.1 KB |
| External Photos | External Photos | 2020-03-11 | PDF 4.6 MB |
| ext Photo diople I | External Photos | 2012-06-11 | PDF 2.6 MB |
| ext Photo diople II | External Photos | 2012-06-11 | PDF 2.7 MB |
| ext photo printed | External Photos | 2012-06-11 | PDF 4.2 MB |
| ext photos dipole 1 | External Photos | 2012-06-11 | PDF 2.6 MB |
| ext photos dipole 2 | External Photos | 2012-06-11 | PDF 2.7 MB |
| ext photos printed | External Photos | 2012-06-11 | PDF 4.2 MB |
| Label Info | ID Label/Location Info | 2020-07-29 | PDF 60 KB |
| Label Info | ID Label/Location Info | 2020-03-11 | PDF 817.8 KB |
| Label | ID Label/Location Info | 2012-06-11 | PDF 67.7 KB |
| Test Setup Photos | Test Setup Photos | 2020-07-29 | PDF 352.3 KB |
| EMC Test Setup Photos | Test Setup Photos | 2020-03-11 | PDF 956 KB |
| RF Test Setup Photos | Test Setup Photos | 2020-03-11 | PDF 2 MB |
| RF Test Setup Photos | Test Setup Photos | 2020-03-11 | PDF 2 MB |
| Test setup | Test Setup Photos | 2016-06-24 | PDF 508.8 KB |
| Test Setup Diople | Test Setup Photos | 2012-06-11 | PDF 424.2 KB |
| Test Setup Printed | Test Setup Photos | 2012-06-11 | PDF 2.2 MB |
| Test Setup Printed | Test Report | 2012-06-11 | PDF 418.9 KB |
| Test Setup photos diople | Test Setup Photos | 2012-06-11 | PDF 424.2 KB |
| Calibration Report | Test Report | 2020-07-29 | PDF 3.2 MB |
| Test Report SAR | Test Report | 2020-07-29 | PDF 2.1 MB |
| Test Report Wi-Fi | Test Report | 2020-07-29 | PDF 2.7 MB |
| Test Report Wi-Fi 1 | Test Report | 2020-07-29 | PDF 2.7 MB |
| Test Report Wi-Fi DTS | Test Report | 2020-07-29 | PDF 2.7 MB |
| Test Report Wi-Fi NII | Test Report | 2020-07-29 | PDF 4.5 MB |
| Test Report Wi-Fi NII Metadata only | Test Report | 2020-07-29 | PDF 4.5 MB |
| Test Report Wi-Fi NII Rev2 | Test Report | 2020-07-29 | PDF 4.5 MB |
| Antenna Photos | Test Report | 2020-03-11 | PDF 136.3 KB |
| Antenna Spec | Test Report | 2020-03-11 | PDF 3.8 MB |
| Atenna Photos | Test Report | 2020-03-11 | PDF 136.3 KB |
| EMC Test Report | Test Report | 2020-03-11 | PDF 889.4 KB |
| RF Test Report | Test Report | 2020-03-11 | PDF 1.8 MB |
| RF Test Report | Test Report | 2020-03-11 | PDF 4.4 MB |
| SAR Test Report | Test Report | 2020-03-11 | PDF 5 MB |
| Test report | Test Report | 2016-06-24 | PDF 2.3 MB |
| DFS Report | Test Report | 2012-06-11 | PDF 1.2 MB |
| Test Report 11an printed | Test Report | 2012-06-11 | PDF 3.1 MB |
| Test Report an | Test Report | 2012-06-11 | PDF 3.1 MB |
| Test Report bgn | Test Report | 2012-06-11 | PDF 4 MB |
| Test Report bgn printed | Test Report | 2012-06-11 | PDF 4 MB |
| Test Report diople 11an Part I | Test Report | 2012-06-11 | PDF 3 MB |
| Test Report diople 11an Part II | Test Report | 2012-06-11 | PDF 3 MB |
| Test Report diople 11an Part III | Test Report | 2012-06-11 | PDF 2.4 MB |
| Test Report printed 11an Part I | Test Report | 2012-06-11 | PDF 3 MB |
| Test Report printed 11an Part II | Test Report | 2012-06-11 | PDF 3 MB |
| Test Report printed 11an Part III | Test Report | 2012-06-11 | PDF 2.4 MB |
| WiFi Attestation Letter | Attestation Statements | 2020-03-11 | PDF 909 KB |
| C2PC Request | Cover Letter(s) | 2020-07-29 | PDF 227.3 KB |
| FCC Lab Authorization Letter | Cover Letter(s) | 2020-07-29 | PDF 151.3 KB |
| Host Model Letter | Cover Letter(s) | 2020-07-29 | PDF 246.2 KB |
| Lab Declaration Authorization | Cover Letter(s) | 2020-07-29 | PDF 152.1 KB |
| Modular Approval Request | Cover Letter(s) | 2020-07-29 | PDF 424.6 KB |
| POA | Cover Letter(s) | 2020-07-29 | PDF 1 MB |
| Request Letter | Cover Letter(s) | 2020-07-29 | PDF 227.3 KB |
| Class II Change Letter | Cover Letter(s) | 2020-03-11 | PDF 3.2 MB |
| Class II Changer Letter | Cover Letter(s) | 2020-03-11 | PDF 3.2 MB |
| Family Certification Information | Cover Letter(s) | 2020-03-11 | PDF 304.3 KB |
| POA | Cover Letter(s) | 2020-03-11 | PDF 1.2 MB |
| Cover letter | Cover Letter(s) | 2016-06-24 | PDF 32.5 KB |
| Ad hoc letter | Cover Letter(s) | 2012-06-11 | PDF 1,005.4 KB |
| DOC letter | Cover Letter(s) | 2012-06-11 | PDF 815.5 KB |
| LTC Request | Cover Letter(s) | 2012-06-11 | PDF 983 KB |
| LTC request | Cover Letter(s) | 2012-06-11 | PDF 983 KB |
| Modular approval letter | Cover Letter(s) | 2012-06-11 | PDF 1.1 MB |
| PoA | Cover Letter(s) | 2012-06-11 | PDF 886.3 KB |
| PoAc | Cover Letter(s) | 2012-06-11 | PDF 886.3 KB |
| UNII letter | Cover Letter(s) | 2012-06-11 | PDF 2.2 MB |
| ad hoc letter | Cover Letter(s) | 2012-06-11 | PDF 1,005.4 KB |
| modular approval letter | Cover Letter(s) | 2012-06-11 | PDF 1.1 MB |
| RF exposure | RF Exposure Info | 2016-06-24 | PDF 119.5 KB |
| MPE bgn | RF Exposure Info | 2012-06-11 | PDF 19.7 KB |
| MPE 11 an printed | RF Exposure Info | 2012-06-11 | PDF 19.6 KB |
| MPE 11an diople | RF Exposure Info | 2012-06-11 | PDF 19.6 KB |
| MPE 11an printed | RF Exposure Info | 2012-06-11 | PDF 19.6 KB |
| MPE an | RF Exposure Info | 2012-06-11 | PDF 19.6 KB |
| printed MPE bgn | RF Exposure Info | 2012-06-11 | PDF 19.7 KB |
| Software security Metadata only | SDR Software/Security Inf | PDF 46.4 KB |
Application Information
| Application ID | bkkCqhFVkl4dLF44JQTMMA== |
|---|---|
| Final Action Date | 2020-07-29 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0010534840 |
| Model | WUBR508N |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 802.11abgn, USB module |
| Responsible Party | Grady Lin, Manager, grady.lin@sparklan.com , +886-2-2659-1880 |
| Test Firm | Mr. Marlin Chen, MRT Technology (Suzhou) Co., Ltd., marlinchen@mrt-cert.com  , +86-512-66308358 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. This device supports 20 and 40 MHz modes. Class II Permissive Change: Adds portable use when integrated into CareView 750Cw, CareView 1500Cw, CareView 1800Cw, CareView 1500P, CareView 1500Cwe and CareView 1800Cwe X-ray Flat Panel Detectors. This implementation involves external PC Board antennas: Ant 1 +5.57 dBi; Ant 2 +4.55 dBi. The highest reported SAR is 0.88 W/kg. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| bkkCqhFVkl4dLF44JQTMMA== | 2020-07-29 | Class II permissive change or modification of presently authorized equipment |
| UTE9B7+vgitHpgiz9N/sng== | 2020-07-29 | Class II permissive change or modification of presently authorized equipment |
| kBaZGoxp9k9GOLFnQP/Syw== | 2020-03-11 | Class II permissive change or modification of presently authorized equipment |
| gcnB5pGOypnfnAyDjyW9OA== | 2020-03-11 | Class II permissive change or modification of presently authorized equipment |
| 69PjupztIvs1NQM4MceY5w== | 2016-06-24 | Class II permissive change or modification of presently authorized equipment |
| v1dfjDL9Hm0i2gEhwpu7VQ== | 2012-06-11 | Original Equipment |
| 82GB00bHPyaz+WdWTQFUkw== | 2012-06-11 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 2412-2462 MHz | 0.0930000 | 15C | CC, MO |
| 2412-2462 MHz | 0.2620000 | 15C | CC, MO |
| 2412-2462 MHz | 0.279 | 15C | CC, MO |
| 2422-2452 MHz | 0.18 | 15C | CC, MO |
| 5180-5240 MHz | 0.0332 | 15E | 38, CC, MO |
| 5180-5240 MHz | 0.025 | 15E | CC, MO |
| 5180-5240 MHz | 0.04 | 15E | CC, MO |
| 5180-5240 MHz | 0.02 | 15E | CC, MO |
| 5190-5230 MHz | 0.036 | 15E | CC, MO |
| 5260-5320 MHz | 0.096 | 15E | 38, CC, MO |
| 5260-5320 MHz | 0.089 | 15E | CC, MO |
| 5260-5320 MHz | 0.109 | 15E | CC, MO |
| 5260-5320 MHz | 0.096 | 15E | CC, MO |
| 5270-5310 MHz | 0.068 | 15E | CC, MO |
| 5500-5700 MHz | 0.083 | 15E | 38, CC, MO |
| 5500-5720 MHz | 0.077 | 15E | CC, MO |
| 5500-5700 MHz | 0.04 | 15E | CC, MO |
| 5500-5700 MHz | 0.083 | 15E | CC, MO |
| 5510-5670 MHz | 0.071 | 15E | CC, MO |
| 5745-5825 MHz | 0.27 | 15C | CC, MO |
| 5745-5825 MHz | 0.1507 | 15E | 38, CC, MO |
| 5745-5825 MHz | 0.111 | 15E | CC, MO |
| 5745-5825 MHz | 0.064 | 15E | CC, MO |
| 5755-5795 MHz | 0.171 | 15C | CC, MO |
Grants
TCB Grant - Application v1dfjDL9Hm0i2gEhwpu7VQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 06/11/2012 Application Dated: 06/11/2012 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Robert Wang , Executive Assistant to CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11abgn USB Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.279 | ||
| CC MO | 15C | 2422.0 - 2452.0 | 0.18 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.27 | ||
| CC MO | 15C | 5755.0 - 5795.0 | 0.171 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz and 5755 to 5795 MHz accordingly. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application v1dfjDL9Hm0i2gEhwpu7VQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 06/11/2012 Application Dated: 06/11/2012 |
| Attention: Robert Wang , Executive Assistant to CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11abgn USB Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.279 | ||
| CC MO | 15C | 2422.0 - 2452.0 | 0.18 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.27 | ||
| CC MO | 15C | 5755.0 - 5795.0 | 0.171 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz and 5755 to 5795 MHz accordingly. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/29/2020 Application Dated: 07/29/2020 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.262 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz. Class II Permissive Change: Adds portable use when integrated into CareView 750Cw, CareView 1500Cw, CareView 1800Cw, CareView 1500P, CareView 1500Cwe and CareView 1800Cwe X-ray Flat Panel Detectors. This implementation involves external PC Board antennas: Ant 1 +2.70 dBi; Ant 2 +1.48 dBi. The highest reported SAR is 0.48 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application UTE9B7+vgitHpgiz9N/sng==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 07/29/2020 Application Dated: 07/29/2020 |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.262 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz. Class II Permissive Change: Adds portable use when integrated into CareView 750Cw, CareView 1500Cw, CareView 1800Cw, CareView 1500P, CareView 1500Cwe and CareView 1800Cwe X-ray Flat Panel Detectors. This implementation involves external PC Board antennas: Ant 1 +2.70 dBi; Ant 2 +1.48 dBi. The highest reported SAR is 0.48 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/11/2020 Application Dated: 03/11/2020 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Flat panel Digital X-ray Detector |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.04 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.109 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.04 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.064 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. This device supports 20 and 40 MHz modes. Class II Permissive Change: Adds portable use when integrated into DRTECH Radiography EVS 4343W / EVS4343WG / EVS 3643W / EVS 3643WG / EVS 4343WP / EVS 3643WP digital x-ray detectors. The highest reported SAR is 0.21 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application kBaZGoxp9k9GOLFnQP/Syw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 03/11/2020 Application Dated: 03/11/2020 |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Flat panel Digital X-ray Detector |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.04 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.109 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.04 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.064 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. This device supports 20 and 40 MHz modes. Class II Permissive Change: Adds portable use when integrated into DRTECH Radiography EVS 4343W / EVS4343WG / EVS 3643W / EVS 3643WG / EVS 4343WP / EVS 3643WP digital x-ray detectors. The highest reported SAR is 0.21 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 03/11/2020 Application Dated: 03/11/2020 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Flat panel Digital X-ray Detector |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.093 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz. Class II Permissive Change: Adds portable use when integrated into DRTECH Radiography EVS 4343W / EVS4343WG / EVS 3643W / EVS 3643WG / EVS 4343WP / EVS 3643WP digital x-ray detectors. The highest reported SAR is <0.10 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application gcnB5pGOypnfnAyDjyW9OA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 03/11/2020 Application Dated: 03/11/2020 |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Flat panel Digital X-ray Detector |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.093 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 2422 to 2452 MHz. Class II Permissive Change: Adds portable use when integrated into DRTECH Radiography EVS 4343W / EVS4343WG / EVS 3643W / EVS 3643WG / EVS 4343WP / EVS 3643WP digital x-ray detectors. The highest reported SAR is <0.10 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/29/2020 Application Dated: 07/29/2020 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.025 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.089 | ||
| CC MO | 15E | 5500.0 - 5720.0 | 0.077 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.111 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. This device supports 20 and 40 MHz modes. Class II Permissive Change: Adds portable use when integrated into CareView 750Cw, CareView 1500Cw, CareView 1800Cw, CareView 1500P, CareView 1500Cwe and CareView 1800Cwe X-ray Flat Panel Detectors. This implementation involves external PC Board antennas: Ant 1 +5.57 dBi; Ant 2 +4.55 dBi. The highest reported SAR is 0.88 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application bkkCqhFVkl4dLF44JQTMMA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 07/29/2020 Application Dated: 07/29/2020 |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.025 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.089 | ||
| CC MO | 15E | 5500.0 - 5720.0 | 0.077 | ||
| CC MO | 15E | 5745.0 - 5825.0 | 0.111 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. This device supports 20 and 40 MHz modes. Class II Permissive Change: Adds portable use when integrated into CareView 750Cw, CareView 1500Cw, CareView 1800Cw, CareView 1500P, CareView 1500Cwe and CareView 1800Cwe X-ray Flat Panel Detectors. This implementation involves external PC Board antennas: Ant 1 +5.57 dBi; Ant 2 +4.55 dBi. The highest reported SAR is 0.88 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
PHOENIX TESTLAB GmbH Koenigswinkel 10 32825 Blomberg, Germany |
Date of Grant: 06/11/2012 Application Dated: 06/11/2012 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Robert Wang , Executive Assistant to CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn USB Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.02 | ||
| CC MO | 15E | 5190.0 - 5230.0 | 0.036 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.096 | ||
| CC MO | 15E | 5270.0 - 5310.0 | 0.068 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.083 | ||
| CC MO | 15E | 5510.0 - 5670.0 | 0.071 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz and 5510 to 5670 MHz accordingly. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 82GB00bHPyaz+WdWTQFUkw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 06/11/2012 Application Dated: 06/11/2012 |
| Attention: Robert Wang , Executive Assistant to CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn USB Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.02 | ||
| CC MO | 15E | 5190.0 - 5230.0 | 0.036 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.096 | ||
| CC MO | 15E | 5270.0 - 5310.0 | 0.068 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.083 | ||
| CC MO | 15E | 5510.0 - 5670.0 | 0.071 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz and 5510 to 5670 MHz accordingly. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 06/24/2016 Application Dated: 06/23/2016 |
| SparkLAN Communications, Inc. |
| 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, |
| Taipei, Taiwan |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0332 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.096 | ||
| 38 CC MO | 15E | 5500.0 - 5700.0 | 0.083 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.1507 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 69PjupztIvs1NQM4MceY5w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SparkLAN Communications, Inc. 8F., No.257, Sec. 2, Tiding Blvd., Neihu District, Taipei, Taiwan |
Date of Grant: 06/24/2016 Application Dated: 06/23/2016 |
| Attention: Grady Lin , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYK-WUBR508N |
| Name of Grantee: | SparkLAN Communications, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11abgn, USB module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0332 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.096 | ||
| 38 CC MO | 15E | 5500.0 - 5700.0 | 0.083 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.1507 |
| Output power listed is the maximum combined conducted output power as indicated in the filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing. This transmitter is restricted to indoor use only within the 5.15-5.25 GHz band. When operating in 802.11n, 40 MHz mode, the operating frequency segment is limited to 5190 to 5230 MHz, 5270 to 5310 MHz, 5510 to 5670 MHz, and 5755 to 5795 MHz accordingly. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
