EYSGCN Wireless Module Teardown Internal Photos - FCC ID RYYEYSGCN
FCC ID RYYEYSGCN
Internal Photos
Wireless Module
Document preview loads when visible.
Document Details
| FCC ID | RYYEYSGCN |
|---|---|
| Document ID | 2717328 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | 19-Taiyo Yuden_EYSGCN_INT photox |
| Applicant | TAIYO YUDEN CO., LTD. |
| Equipment Class | Wireless Module |
| Product Code | EYSGCN |
| Application ID | dS+2o9XPuKdhpk6usac1Uw== |
| Application Purpose | Original Equipment |
| Application Date | 2015-08-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0008738361 |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch |
| Certified By | Manabu Satomi Deputy Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 02/02/2016 |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2015-08-18 |
| Available | 2016-02-02 |
| Created | 2015-08-07 |
| Modified | 2015-08-07 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 288447 |
| File SHA-256 | e0a579b7ac13d593cce05fd8d66d1a5e1483e7bfa3f3ee6ee30fe654bcccb3e2 |
| PDF Metadata Author | jt0020821 |
| PDF Metadata Producer | jt0020821 Acrobat Distiller 8.1.0 (Windows) |
| FCC.gov Sources | FCC.gov 2717328 |
