FCC ID RYYWYSAAVDXB-E
Wireless Module
by TAIYO YUDEN CO., LTD.
Grantee Code: RYY Product Code: WYSAAVDXBE
Latest application date: 2016-02-17
Device Images
FCC ID Device Details
| FCC ID | RYYWYSAAVDXB-E |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RYY |
| Product Code | WYSAAVDXBE |
| Applicant Business | TAIYO YUDEN CO., LTD. 🇯🇵 |
| Related Domains |  jty.yuden.co.jp |
| Equipment Class | Wireless Module |
| Test Firm | KEC Electronic Industry Development Center |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-17 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-17 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-17 |
| 2402-2480 MHz | Original Equipment | 2015-07-29 |
| 2412-2462 MHz | Original Equipment | 2015-07-29 |
| 5180-5240 MHz | Original Equipment | 2015-07-29 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-02-17 | PDF 5.9 MB |
| User manual (FCC)_WYSAAVDXB | Users Manual | 2016-01-09 | PDF 408.6 KB |
| User manual_EN_H725A | Users Manual | 2016-01-09 | PDF 5.9 MB |
| User manual_FR_H725A | Users Manual | 2016-01-09 | PDF 4.8 MB |
| Internal photo | Internal Photos | 2016-02-17 | PDF 229.8 KB |
| External photo & Internal photo_H725A | External Photos | 2016-01-09 | PDF 410.5 KB |
| Internal photo_WYSAAVDXB | Internal Photos | 2016-01-09 | PDF 118.6 KB |
| External photo_WYSAAVDXB | External Photos | 2016-01-09 | PDF 103.1 KB |
| ID label/Location info | ID Label/Location Info | 2016-02-17 | PDF 58.7 KB |
| ID Label_H725A | ID Label/Location Info | 2015-07-29 | PDF 69 KB |
| ID Label_WYSAAVDXB | ID Label/Location Info | 2015-07-29 | PDF 49.3 KB |
| Label location info_H725A | ID Label/Location Info | 2015-07-29 | PDF 84.4 KB |
| Test setup photo_15A005C_APPENDIX | Test Setup Photos | 2016-02-17 | PDF 721.3 KB |
| Test setup photo_15A063B_APPENDIX | Test Setup Photos | 2016-02-17 | PDF 762.3 KB |
| Test setup photo | Test Setup Photos | 2016-01-09 | PDF 479.1 KB |
| Test setup photo | Test Setup Photos | 2016-01-09 | PDF 63.6 KB |
| Test setup photo_SAR | Test Setup Photos | 2016-01-09 | PDF 93.8 KB |
| Test report | Test Report | 2016-02-17 | PDF 566.7 KB |
| Test report_RF | Test Report | 2015-07-29 | PDF 3.8 MB |
| Test report_RF | Test Report | 2015-07-29 | PDF 2.5 MB |
| Test report_SAR | RF Exposure Info | 2015-07-29 | PDF 463.3 KB |
| Test report_SAR_Appendix 1 | RF Exposure Info | 2015-07-29 | PDF 344.9 KB |
| Test report_SAR_Appendix 2 | RF Exposure Info | 2015-07-29 | PDF 402.6 KB |
| Test report_SAR_Appendix 3 | RF Exposure Info | 2015-07-29 | PDF 1.1 MB |
| Test report_SAR_Appendix 4 | RF Exposure Info | 2015-07-29 | PDF 1.4 MB |
| C2PC letter | Cover Letter(s) | 2016-02-17 | PDF 23.4 KB |
| FCC Exposure DeclarationRef. No.14056-FCC-001 | Cover Letter(s) | 2016-02-17 | PDF 25.4 KB |
| FCC Exposure EvaluationSimultaneousRef. No.14056-FCC-004 | Cover Letter(s) | 2016-02-17 | PDF 101.5 KB |
| FCC Exposure EvaluationStandaloneRef. No.14056-FCC-002 | Cover Letter(s) | 2016-02-17 | PDF 138.7 KB |
| FCC Exposure EvaluationStandaloneRef. No.14056-FCC-003 | Cover Letter(s) | 2016-02-17 | PDF 191.1 KB |
| Antenna specification | Cover Letter(s) | 2015-07-29 | PDF 216.9 KB |
| Cover Letter for Form 731 | Cover Letter(s) | 2015-07-29 | PDF 25.3 KB |
| Modular Approval Request | Cover Letter(s) | 2015-07-29 | PDF 104.2 KB |
| confidentiality | Cover Letter(s) | 2015-07-29 | PDF 20.1 KB |
| FCC Exposure Declaration | RF Exposure Info | 2015-07-29 | PDF 25.4 KB |
| FCC Exposure Evaluation(EYSFCN) | RF Exposure Info | 2015-07-29 | PDF 191.1 KB |
| FCC Exposure Evaluation(Simultaneous) | RF Exposure Info | 2015-07-29 | PDF 101.5 KB |
| FCC Exposure Evaluation(WYSAAVDXB-E) | RF Exposure Info | 2015-07-29 | PDF 138.7 KB |
| Block diagram Metadata only | Block Diagram | PDF 37.6 KB | |
| Schematics Metadata only | Schematics | PDF 44.6 KB | |
| Operational description Metadata only | Operational Description | PDF 49.3 KB | |
| Operational description-1 Metadata only | Operational Description | PDF 49.3 KB | |
| Operational description-2 Metadata only | Operational Description | PDF 39.2 KB | |
| Parts list Metadata only | Parts List/Tune Up Info | PDF 17.7 KB |
Application Information
| Application ID | via+m/QV+wwUjmrJxuCPgw== |
|---|---|
| Final Action Date | 2016-02-17 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0008738361 |
| Model | WYSAAVDXB-E |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Wireless Module |
| Responsible Party | Hideki Kato, Deputy General Manager, ty-approval@jty.yuden.co.jp , 81-27-346-9185 |
| Technical Contact | Hiroyuki Masuda, TAIYO YUDEN CO., LTD., ty-approval@jty.yuden.co.jp , 81-27-324-2313 |
| Non-Technical Contact | Chiharu Sakai, TAIYO YUDEN CO., LTD., ty-approval@jty.yuden.co.jp , 81-27-324-2313 |
| Test Firm | Seiichi Izumi, KEC Electronic Industry Development Center, Izumi@kec.jp  , 81-774-29-9139 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| via+m/QV+wwUjmrJxuCPgw== | 2016-02-17 | Class II permissive change or modification of presently authorized equipment |
| CfMaseraahc8WKl9HM9BiQ== | 2016-02-17 | Class II permissive change or modification of presently authorized equipment |
| 3Pxp+66BhJBV4ILEQzUmJQ== | 2016-02-17 | Class II permissive change or modification of presently authorized equipment |
| oefelKEd7sADy86w7QMWyQ== | 2015-07-29 | Original Equipment |
| nzYZkemPUMAEXq4qCAxWcg== | 2015-07-29 | Original Equipment |
| J1a6HsHw4ndwzRYtweeFYg== | 2015-07-29 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application via+m/QV+wwUjmrJxuCPgw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.00094 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application via+m/QV+wwUjmrJxuCPgw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.00094 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.00094 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for simultaneous transmission exposure condition is 0.12 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application oefelKEd7sADy86w7QMWyQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.00094 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for simultaneous transmission exposure condition is 0.12 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.161 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 0.15 W/kg and 0.23 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application nzYZkemPUMAEXq4qCAxWcg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.161 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 0.15 W/kg and 0.23 W/kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.014 | ||
| 38 CC | 15E | 5260.0 - 5320.0 | 0.014 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.014 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.015 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 0.67 W/kg and 0.75 W/kg, respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application J1a6HsHw4ndwzRYtweeFYg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 07/29/2015 Application Dated: 07/29/2015 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.014 | ||
| 38 CC | 15E | 5260.0 - 5320.0 | 0.014 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.014 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.015 |
| Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna(s) used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. This application covers the use of the module in Smart headset, H725A from EPSON. The highest reported SAR for stand-alone and simultaneous transmission exposure conditions are 0.67 W/kg and 0.75 W/kg, respectively. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.014 | ||
| 38 CC ND | 15E | 5260.0 - 5320.0 | 0.014 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.014 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.015 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application CfMaseraahc8WKl9HM9BiQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.014 | ||
| 38 CC ND | 15E | 5260.0 - 5320.0 | 0.014 | ||
| 38 CC ND | 15E | 5500.0 - 5700.0 | 0.014 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.015 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.161 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 3Pxp+66BhJBV4ILEQzUmJQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 02/17/2016 Application Dated: 02/04/2016 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSAAVDXB-E |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.161 |
| Class II Permissive Change : This change is to evaluate simultaneous transmission with another transmitter(Single Modular, FCC ID RYYEYSFCN) when combining them within a specific host (H725A from EPSON). The highest reported SAR value for simultaneous transmission use condition is 0.75 W/kg. Output Power listed is conducted. This module may only be installed by the OEM or an OEM integrator in the products as specified in this filing. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. OEM integrators must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
