FCC ID RYYWYSACVLXY
CPU Embedded WLAN Module
by TAIYO YUDEN CO., LTD.
Grantee Code: RYY Product Code: WYSACVLXY
Latest application date: 2015-11-13
Device Images
FCC ID Device Details
| FCC ID | RYYWYSACVLXY |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | RYY |
| Product Code | WYSACVLXY |
| Applicant Business | TAIYO YUDEN CO., LTD. 🇯🇵 |
| Related Domains |  jty.yuden.co.jp |
| Equipment Class | CPU Embedded WLAN Module |
| Test Firm | UL Japan, Inc. Shonan EMC EMC Lab. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-11-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-11-13 | PDF 45 KB |
| Internal Photo | Internal Photos | 2015-11-13 | PDF 24.2 KB |
| External Photo | External Photos | 2015-11-13 | PDF 108.3 KB |
| Label and Location | ID Label/Location Info | 2015-11-13 | PDF 57.3 KB |
| FCC Test Setup Photo_DTS | Test Setup Photos | 2015-11-13 | PDF 798.8 KB |
| FCC Test Report_DTS | Test Report | 2015-11-13 | PDF 728 KB |
| FCC Authorization Letter | Cover Letter(s) | 2015-11-13 | PDF 29.5 KB |
| FCC MA Letter | Cover Letter(s) | 2015-11-13 | PDF 61.7 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2015-11-13 | PDF 24 KB |
| FCC RF Exposure_DTS | RF Exposure Info | 2015-11-13 | PDF 53.5 KB |
| (Confidential) Block Diagram Metadata only | Block Diagram | PDF 54.6 KB | |
| (Confidential) Schematics Metadata only | Schematics | PDF 65.2 KB | |
| (Confidential) Theory of Operation-Antenna Specification Metadata only | Operational Description | PDF 166.6 KB | |
| (Confidential) Theory of Operation-Interface Specification Metadata only | Operational Description | PDF 613.1 KB |
Application Information
| Application ID | nFtNwjCpqnZasGzxe8mj8A== |
|---|---|
| Final Action Date | 2015-11-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0008738361 |
| Model | WYSACVLXY |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | CPU Embedded WLAN Module |
| Responsible Party | Hideki Kato, Deputy General Manager, ty-approval@jty.yuden.co.jp , 81-27-346-9185 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Toyokazu Imamura, UL Japan, Inc., Toyokazu.Imamura@ul.com , 81-463-50-6400 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Shonan EMC EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power listed is Conducted(Peak). Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| nFtNwjCpqnZasGzxe8mj8A== | 2015-11-13 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0861000 | 15C |
Grants
TCB Grant - Application nFtNwjCpqnZasGzxe8mj8A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 11/13/2015 Application Dated: 11/13/2015 |
| TAIYO YUDEN CO., LTD. |
| 43-1, Yawatabara-machi |
| Takasaki-shi, Gunma, 370-0024 Japan |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSACVLXY |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | CPU Embedded WLAN Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0861 |
| Single Modular Approval. Output power listed is Conducted(Peak). Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. |
EAS Grant - Application nFtNwjCpqnZasGzxe8mj8A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TAIYO YUDEN CO., LTD. 43-1, Yawatabara-machi Takasaki-shi, Gunma, 370-0024 Japan |
Date of Grant: 11/13/2015 Application Dated: 11/13/2015 |
| Attention: Hideki Kato , Deputy General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | RYYWYSACVLXY |
| Name of Grantee: | TAIYO YUDEN CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | CPU Embedded WLAN Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0861 |
| Single Modular Approval. Output power listed is Conducted(Peak). Separate evaluation must be required for any portable configuration. When used in mobile applications, the antennas shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific information required to satisfy RF exposure compliance for the final host device. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antenna of this device must not be co-located or used in conjunction with any other antenna or transmitter except for the conditions shown in this filing and/or in accordance with FCC multi-transmitter product guidelines. |
