FCC ID S6T784
WiFi Module with integrated TCP/IP protocol stack
by Tekelek Europe Ltd
Grantee Code: S6T Product Code: 784
Latest application date: 2017-03-10
Device Images
FCC ID Device Details
| FCC ID | S6T784 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | S6T |
| Product Code | 784 |
| Applicant Business | Tekelek Europe Ltd 🇮🇪 |
| Related Domains |  tekelek.ie |
| Equipment Class | WiFi Module with integrated TCP/IP protocol stack |
| Test Firm | Compliance Engineering Ireland Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-03-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Installation Manual | Users Manual | 2017-03-10 | PDF 473 KB |
| User Manual Statements | Users Manual | 2017-03-10 | PDF 18 KB |
| Internal Photos | Internal Photos | 2017-03-10 | PDF 51 KB |
| External Photos | External Photos | 2017-03-10 | PDF 43.7 KB |
| Product Label | ID Label/Location Info | 2017-03-10 | PDF 381.1 KB |
| Test Setup Photos | Test Setup Photos | 2017-03-10 | PDF 408.2 KB |
| Test Report | Test Report | 2017-03-10 | PDF 3.8 MB |
| Modular Approval Cover Letter | Cover Letter(s) | 2017-03-10 | PDF 20 KB |
| Request for Confidentiality and Agent Authorization | Cover Letter(s) | 2017-03-10 | PDF 24.5 KB |
| MPE Calculation | RF Exposure Info | 2017-03-10 | PDF 115.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 52 KB | |
| PCB Antenna Details Metadata only | Schematics | PDF 515.3 KB | |
| Schematics Metadata only | Schematics | PDF 22 KB | |
| Operational Description Metadata only | Operational Description | PDF 445 KB |
Application Information
| Application ID | dB0dm38ARhtMOU5Gd7f/iQ== |
|---|---|
| Final Action Date | 2017-03-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013214499 |
| Model | 784 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi Module with integrated TCP/IP protocol stack |
| Responsible Party | Martin Callanan, Engineering Manager, martin.callanan@tekelek.ie , +353-61-471511 |
| Agent | John John John, Compliance Engineering, john.mcauley@cei.ie  , 003538256722 |
| Technical Contact | Rory Keating, Tekelek Europe, rory.keating@tekelek.ie , 35361471511 |
| Non-Technical Contact | Martin Callinan, Tekelek Europe, martin.callinan@tekelek.ie , 35361471511 |
| Test Firm | John McAuley, Compliance Engineering Ireland Ltd., john.mcauley@cei.ie , 353-1-8256722 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted average. Limited Single Modular Approval. This device is granted for use in mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. This module can only be used in hosts, which are battery operated and designed by the module manufacturer, with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| dB0dm38ARhtMOU5Gd7f/iQ== | 2017-03-10 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0100000 | 15C |
Grants
TCB Grant - Application dB0dm38ARhtMOU5Gd7f/iQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 03/10/2017 Application Dated: 03/10/2017 |
| Tekelek Europe Ltd |
| Shannon Free Zone |
| Shannon |
| Co. Clare, Ireland |
| Attention: Martin Callanan , Engineering Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | S6T784 |
| Name of Grantee: | Tekelek Europe Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Module with integrated TCP/IP protocol stack |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.01 |
| Power output listed is conducted average. Limited Single Modular Approval. This device is granted for use in mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. This module can only be used in hosts, which are battery operated and designed by the module manufacturer, with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. |
EAS Grant - Application dB0dm38ARhtMOU5Gd7f/iQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Tekelek Europe Ltd Shannon Free Zone Shannon Co. Clare, Ireland |
Date of Grant: 03/10/2017 Application Dated: 03/10/2017 |
| Attention: Martin Callanan , Engineering Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | S6T784 |
| Name of Grantee: | Tekelek Europe Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi Module with integrated TCP/IP protocol stack |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.01 |
| Power output listed is conducted average. Limited Single Modular Approval. This device is granted for use in mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. This module can only be used in hosts, which are battery operated and designed by the module manufacturer, with a host antenna circuit trace layout design in strict compliance with the OEM instructions provided. The Grantee is responsible for providing the documentation required for modular use. The responsibility for the use of this module, in all configurations utilized or contemplated, remains with the Grantee. |
