EM190F Car MP3 Player Schematics - FCC ID S7JEM190F

FCC ID S7JEM190F

Schematics 1

Car MP3 Player

by Shenzhen Yifang Digital Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDS7JEM190F
Document ID540624
Document TypeSchematics
DescriptionSchematics 1
Document TitleProtel Schematic
ApplicantShenzhen Yifang Digital Technology Co., Ltd.
Equipment ClassCar MP3 Player
Product CodeEM190F
Application IDsLvSzzWdxKb5Pz8fVDuLbg==
Application PurposeOriginal Equipment
Application Date2005-05-10
Frequency Range88.1-88.9 MHz
FRN0013275144
Test FirmAccurate Technology Co., Ltd.
Certified BySean Liu Agent
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-05-10
Available2005-05-10
Created2005-03-28
Modified2005-03-28
Pages1
File TypeAdobe Acrobat PDF
File Size142274
File SHA-25653c2bcc14bac2f2ef20ff43204bf4dc0e2101589e5ad2c157758e5b828d83c3c
PDF Metadata Authoryounger
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) younger
FCC.gov SourcesFCC.gov 540624
