R510 ZoneFlex R510 Access Point Test Setup Photos - FCC ID S9GR510
FCC ID S9GR510
Test Setup Photos
ZoneFlex R510 Access Point
Document preview loads when visible.
Document Details
| FCC ID | S9GR510 |
|---|---|
| Document ID | 2900514 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | FCC_IC RF_SL15073101-RUC-023_DTS |
| Applicant | Ruckus Wireless, Inc. |
| Equipment Class | ZoneFlex R510 Access Point |
| Product Code | R510 |
| Application ID | jv3FdPT5gEKG2+62XB9OHQ== |
| Application Purpose | Original Equipment |
| Application Date | 2016-02-10 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0013389887 |
| Test Firm | Bureau Veritas Consumer Products Services, Inc. |
| Certified By | Clinton Bradley |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 08/08/2016 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-02-10 |
| Available | 2016-08-08 |
| Created | 2016-02-01 |
| Modified | 2016-02-01 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 222842 |
| File SHA-256 | cadc8780bfe3d829babde2df6a0f890ff64d6584bbf5ee575de92f15875c4842 |
| PDF Metadata Author | Angela |
| PDF Metadata Producer | Acrobat Distiller 11.0 (Windows) Angela |
| FCC.gov Sources | FCC.gov 2900514, FCC.gov 2900463 |
