ICEMFILT3C ICEMAKERS TRANSMITTER... - FCC ID SB8-ICEM-FIL-T-3C

FCC ID SB8-ICEM-FIL-T-3C

SCHEMATICS

ICEMAKERS TRANSMITTER

by ICEM Enterprises, Inc.

Document preview loads when visible.

Document Details

FCC IDSB8-ICEM-FIL-T-3C
Document ID450078
Document TypeSchematics
DescriptionSCHEMATICS
Document TitleSCH_FIL-3C-T
ApplicantICEM Enterprises, Inc.
Equipment ClassICEMAKERS TRANSMITTER
Product CodeICEMFILT3C
Application IDsY+uxgvS+fQNhLX1meH7dA==
Application PurposeOriginal Equipment
Application Date2004-07-16
Frequency Range417.7-418.3 MHz
FRN0011202041
Test FirmCarl T. Jones Corporation
Certified ByROGER EPWORTH PRESIDENT
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-07-16
Available2004-07-16
Created2004-06-10
Modified2004-06-10
Pages3
File TypeAdobe Acrobat PDF
File Size132103
File SHA-256cf1d6688a7a9ef162054dfa7a44e3e687b4fc6bf9bcbbf8faa7c3fac8fcbc6a0
PDF Metadata AuthorROGER EPWORTH
PDF Metadata ProducerSCH_FIL Acrobat PDFWriter 3.02 for Windows
FCC.gov SourcesFCC.gov 450078
