K812 NEXT B-TAG July 2017 Ver Reader/Writer... - FCC ID SBDK812

FCC ID SBDK812

03 FCC Test Setup Photo_DCD

NEXT B-TAG July 2017 Ver Reader/Writer Outer case

by Bridgestone Corporation

Document preview loads when visible.

Document Details

FCC IDSBDK812
Document ID3526633
Document TypeTest Setup Photos
Description03 FCC Test Setup Photo_DCD
ApplicantBridgestone Corporation
Equipment ClassNEXT B-TAG July 2017 Ver Reader/Writer Outer case
Product CodeK812
Application IDDrQ9KWn/M4JQJgCZcUze9A==
Application PurposeOriginal Equipment
Application Date2017-08-25
Frequency Range0.125 MHz
FRN0003180007
Test FirmUL Japan, Inc. Shonan EMC EMC Lab.
Certified ByYoshihisa Maeda Project Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-08-25
Available2017-08-25
Created2017-08-01
Modified2017-08-24
Pages2
File TypeAdobe Acrobat PDF
File Size665629
File SHA-2561dffcb40e321f381b42e9cb45d20e40d39ff2a1dc6e76f230de9e9fdd5e64923
PDF Metadata ProducerPScript5.dll Version 5.2.2 Acrobat Distiller 10.1.2 (Windows)
FCC.gov SourcesFCC.gov 3526633
