CERTIFICATION TEST REPORT
Report Number. : 12166253-E1V3
Applicant :
Model :
FCC ID :
IC :
SONOS INC.
614 CHAPALA STREET
SANTA BARBARA, CA 93101, U.S.A
S18
SBVRM016
5373A-RM016
EUT Description :
802.11 a/b/g/n HT20 CLIENT DEVICE
Test Standard(s) :
FCC 47 CFR PART 15 SUBPART C
ISED RSS-247 ISSUE 2
ISED RSS-GEN ISSUE 5
Date Of Issue:
October 10, 2018
Prepared by:
UL Verification Services Inc.
47173 Benicia Street
Fremont, CA 94538 U.S.A.
TEL: (510) 771-1000
FAX: (510) 661-0888
NVLAP Lab code: 200065-0
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
REPORT REVISION HISTORY
Issue
Date
Revisions
Revised By
V1
9/13/2018
Initial Issue
V2
10/1/2018
Updated Section 2 & 6
K.Kedida
V3
10/10/2018
Updated Section 9.3
K.Kedida
Rev.
Page 2 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
TABLE OF CONTENTS
REPORT REVISION HISTORY ................................................................................................. 2
TABLE OF CONTENTS ............................................................................................................ 3
1.
ATTESTATION OF TEST RESULTS ................................................................................. 5
2.
TEST METHODOLOGY ..................................................................................................... 6
3.
FACILITIES AND ACCREDITATION ................................................................................. 6
4.
CALIBRATION AND UNCERTAINTY ................................................................................ 7
5.
4.1.
MEASURING INSTRUMENT CALIBRATION .............................................................. 7
4.2.
SAMPLE CALCULATION ............................................................................................ 7
4.3.
MEASUREMENT UNCERTAINTY ............................................................................... 7
EQUIPMENT UNDER TEST ............................................................................................... 8
5.1.
EUT DESCRIPTION .................................................................................................... 8
5.2.
MAXIMUM OUTPUT POWER...................................................................................... 8
5.3.
DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 8
5.4.
SOFTWARE AND FIRMWARE .................................................................................... 8
5.5.
WORST-CASE CONFIGURATION AND MODE .......................................................... 8
5.6.
DESCRIPTION OF TEST SETUP ................................................................................ 9
6.
MEASUREMENT METHOD...............................................................................................11
7.
TEST AND MEASUREMENT EQUIPMENT ......................................................................12
8.
ANTENNA PORT TEST RESULTS ...................................................................................13
9.
8.1.
ON TIME AND DUTY CYCLE .....................................................................................13
8.2.
99% BANDWIDTH ......................................................................................................14
8.3.
6 dB BANDWIDTH ......................................................................................................15
8.4.
OUTPUT POWER.......................................................................................................16
8.5.
AVERAGE POWER ....................................................................................................17
8.6.
POWER SPECTRAL DENSITY ..................................................................................18
8.7.
CONDUCTED SPURIOUS EMISSIONS .....................................................................19
RADIATED TEST RESULTS .............................................................................................21
9.1.
LIMITS AND PROCEDURE ........................................................................................21
9.2.
TRANSMITTER ABOVE 1 GHz ..................................................................................22
9.3.
Worst Case Below 30 MHz .........................................................................................32
9.4.
Worst Case Below 1 GHz ...........................................................................................33
Page 3 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
9.5.
DATE: 10/10/2018
IC: 5373A-RM016
Worst Case 18-26 GHz ...............................................................................................35
10.
AC POWER LINE CONDUCTED EMISSIONS ..............................................................37
11.
SETUP PHOTOS ...........................................................................................................40
Page 4 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
1. ATTESTATION OF TEST RESULTS
COMPANY NAME:
SONOS INC.
614 CHAPALA STREET
SANTA BARBARA, CA 93101, U.S.A
EUT DESCRIPTION:
802.11a/b/g/n HT20 CLIENT DEVICE
MODEL:
S18
SERIAL NUMBER:
78-28-CA-F0-00-2E-C (Radiated Sample)
78-28-CA-F0-00-14 (Conducted Sample)
DATE TESTED:
July 23 – 30, 2018
APPLICABLE STANDARDS
STANDARD
TEST RESULTS
CFR 47 Part 15 Subpart C
Complies
ISED RSS-247 Issue 2
Complies
ISED RSS-GEN Issue 5
Complies
UL Verification Services Inc. tested the above equipment in accordance with the requirements
set forth in the above standards. All indications of Pass/Fail in this report are opinions
expressed by UL Verification Services Inc. based on interpretations and/or observations of test
results. Measurement Uncertainties were not taken into account and are published for
informational purposes only. The test results show that the equipment tested is capable of
demonstrating compliance with the requirements as documented in this report.
Note: The results documented in this report apply only to the tested sample, under the
conditions and modes of operation as described herein. This document may not be altered or
revised in any way unless done so by UL Verification Services Inc. and all revisions are duly
noted in the revisions section. Any alteration of this document not carried out by UL Verification
Services Inc. will constitute fraud and shall nullify the document. This report must not be used
by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any
agency of the Federal Government, or any agency of the U.S. government.
Approved & Released For
UL Verification Services Inc. By:
Reviewed By:
DAN CORONIA
CONSUMER TECHNOLOGY DIVISION
OPERATIONS LEADER
UL Verification Services Inc.
Kiya Kedida
CONSUMER TECHNOLOGY DIVISION
PROJECT ENGINEER
UL Verification Services Inc
Page 5 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
2. TEST METHODOLOGY
The tests documented in this report were performed in accordance with FCC CFR 47 Part 2,
FCC CFR 47 Part 15, KDB 558074 D01 v5, ANSI C63.10-2013, RSS-GEN Issue 5, and RSS247 Issue 2.
3. FACILITIES AND ACCREDITATION
The test sites and measurement facilities used to collect data are located at 47173 and 47266
Benicia Street, and 47658 Kato Road, Fremont, California, USA. Line conducted emissions are
measured only at the 47173 address. The following table identifies which facilities were utilized
for radiated emission measurements documented in this report. Specific facilities are also
identified in the test results sections.
47173 Benicia Street
☐ Chamber A (ISED:2324B-1)
☒ Chamber B (ISED:2324B-2)
☐ Chamber C (ISED:2324B-3)
47266 Benicia Street
☐
☐
☐
☐
☐
Chamber D (ISED:22541-1)
Chamber E (ISED:22541-2)
Chamber F (ISED:22541-3)
Chamber G (ISED:22541-4)
Chamber H (ISED:22541-5)
47658 Kato Rd.
☐ Chamber K (ISED: 2324A-1)
☐ Chamber L (ISED: 2324A-3)
The above test sites and facilities are covered under FCC Test Firm Registration # 208313.
Chambers A through C are covered under ISED company address code 2324B with site
numbers 2324B -1 through 2324B-3, respectively. Chambers D through H are covered under
ISED company address code 22541 with site numbers 22541 -1 through 22541-5, respectively.
Chambers K and L are covered under ISED company address code 2324A with site numbers
2324A-1 and 2324A-3, respectively.
UL Verification Services Inc. is accredited by NVLAP, Laboratory Code 200065-0
Page 6 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
4. CALIBRATION AND UNCERTAINTY
4.1.
MEASURING INSTRUMENT CALIBRATION
The measuring equipment utilized to perform the tests documented in this report has been
calibrated in accordance with the manufacturer's recommendations, and is traceable to
recognized national standards.
4.2.
SAMPLE CALCULATION
Where relevant, the following sample calculation is provided:
Field Strength (dBuV/m) = Measured Voltage (dBuV) + Antenna Factor (dB/m) +
Cable Loss (dB) – Preamp Gain (dB)
36.5 dBuV + 18.7 dB/m + 0.6 dB – 26.9 dB = 28.9 dBuV/m
4.3.
MEASUREMENT UNCERTAINTY
Where relevant, the following measurement uncertainty levels have been estimated for tests
performed on the apparatus:
PARAMETER
Worst Case Conducted Disturbance, 9KHz to 0.15 MHz
Worst Case Conducted Disturbance, 0.15 to 30 MHz
Worst Case Radiated Disturbance, 9KHz to 30 MHz
Worst Case Radiated Disturbance, 30 to 1000 MHz
Worst Case Radiated Disturbance, 1000 to 18000 MHz
Worst Case Radiated Disturbance, 18000 to 26000 MHz
Worst Case Radiated Disturbance, 26000 to 40000 MHz
UNCERTAINTY
3.84 dB
3.65 dB
3.15 dB
5.36 dB
4.32 dB
4.45 dB
5.24 dB
Uncertainty figures are valid to a confidence level of 95%.
Page 7 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
5. EQUIPMENT UNDER TEST
5.1.
EUT DESCRIPTION
The EUT is 802.11a/b/g/n HT20 CLIENT DEVICE.
5.2.
MAXIMUM OUTPUT POWER
The transmitter has a maximum peak conducted output power as follows:
Frequency
Range
(MHz)
2402 - 2480
5.3.
Mode
Output Power
(dBm)
Output Power
(mW)
BLE
-0.96
0.80
DESCRIPTION OF AVAILABLE ANTENNAS
The radio utilizes Printed Circuit Board (PCB) antenna, with a maximum gain of 3.9 dBi.
5.4.
SOFTWARE AND FIRMWARE
The EUT software ware installed during testing was 44.2-53220-RF-Complianc_20180523.
The test utility software used during testing was Sonos Compliance GUI V2.2.
5.5.
WORST-CASE CONFIGURATION AND MODE
Radiated bandage, harmonics, and spurious emissions from 1 GHz to 18GHz were performed.
The EUT was set to transmit at the Low/Middle/High channels with designed (target) output
powers.
Radiated emission below 1GHz, above 18GHz, and power line conducted emission were
performed with the EUT was set to transmit at the channel with highest output power as worstcase scenario.
The EUT can only be setup in desktop orientation; therefore, all radiated testing was performed
with the EUT in desktop orientation.
Page 8 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
5.6.
DATE: 10/10/2018
IC: 5373A-RM016
DESCRIPTION OF TEST SETUP
SUPPORT EQUIPMENT
Description
Laptop
AC Adapter
Charging Base
Support Equipment List
Manufacturer Model
Serial Number
Lenovo
X201
SON-00000964
Lenovo
ADLX65NLT2A
11S36200291ZZ200315AJU
Lenovo
X200
1S43R8781R934HPB
FCC ID
N/A
N/A
N/A
I/O CABLES
Cable
No
Port
# of identical
ports
AC Power
Ethernet
DC Power
AC Power
I/O Cable List
Connector
Cable Type
Type
AC
RJ45
DC
AC
Unshielded
Unshielded
Shielded
Unshielded
Cable
Length (m)
Remarks
10
1.2
AC Mains to EUT
EUT to Laptop
AC/DC Adapter to Laptop
AC Mains to AC/DC Adapter
TEST SETUP
The EUT is a stand-alone unit, and the radio is exercised by Sonos Compliance GUI V2.2 test
utility software via Ethernet.
Page 9 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
SETUP DIAGRAM
Page 10 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
DATE: 10/10/2018
IC: 5373A-RM016
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
6. MEASUREMENT METHOD
On Time and Duty Cycle: ANSI C63.10-2013 Section 11.6.
6 dB BW: ANSI C63.10 Section 11.8.1. Option 1
Output Power: ANSI C63.10 Section 11.9.2.3.2 Method AVGPM-G (Measurement using a
gated RF average-reading power meter)
Power Spectral Density: ANSI C63.10 Section 11.10.3 Method AVGPSD-1.
Radiated emissions non-restricted frequency bands: ANSI C63.10 Section 11.12.1
Radiated emissions restricted frequency bands: ANSI C63.10 Section 11.12.1.
Conducted emissions in restricted frequency bands: ANSI C63.10 Section 11.12.2.
Band-edge: ANSI C63.10 Subclause -11.13.3.4 Integration method -Trace averaging across ON
and OFF times DC correction
AC Power Line Conducted Emissions: ANSI C63.10-2013, Section 6.2.
Page 11 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
7. TEST AND MEASUREMENT EQUIPMENT
The following test and measurement equipment was utilized for the tests documented in this
report:
TEST EQUIPMENT LIST
Description
Amplifier, 100kHz to 1GHz,
32dB
Antenna, Broadband Hybrid,
30MHz to 2000MHz
Antenna, Horn 1-18GHz
Manufacturer
Model
ID Num
Cal Due
Hewlet Packard
8447D
T15
08/14/2018
Sunol Sciences Corp.
JB1
T407
05/10/2019
ETS-Lindgren
3117
AFS42-00101800-25-S42
AMF-4D-01000800-3029P
T863
06/21/2019
T1165
04/23/2019
T1573
04/03/2019
N9030A
T1450
02/05/2019
N9030A
T1113
12/21/2018
N9030A
T1466
04/16/2019
N1911A
T1271
07/17/2019
N1921A
T1225
04/10/2019
Com-Power Corp.
AL-130R
T1866
10/10/2018
Seavey Division
Agilent
Rohde & Schwarz
FCC INC.
MWH-1826/B
8449B
ESR
FCC LISN 50/250
T89
T404
T1436
T1310
01/18/2019
03/09/2019
02/21/2019
06/15/2019
RF Amplifier
MITEQ
Amplifier, 1 to 8GHz, 35dB
Miteq Inc.
Spectrum Analyzer, PXA, 3Hz
to 44GHz
Spectrum Analyzer, PXA, 3Hz
to 44GHz
Spectrum Analyzer, PSA, 3Hz
to 44GHz
Power Meter, P-series single
channel
Power Sensor, P-series,
50MHz to 18GHz, Wideband
Antenna, Active Loop 9kHz30MHz
18 - 26.5 GHz Horn Antenna
Pre-Amp 1-26.5 GHz
EMI Receiver
L.I.S.N.
Agilent (Keysight)
Technologies
Agilent (Keysight)
Technologies
Agilent (Keysight)
Technologies
Agilent (Keysight)
Technologies
Agilent (Keysight)
Technologies
Test Software List
Description
Manufacturer
Model
Radiated Software
UL
UL EMC
Ver 9.5, June 22, 2018
Antenna Port Software
UL
UL RF
Ver 8.4, June 12, 2018
Page 12 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
Version
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
8. ANTENNA PORT TEST RESULTS
8.1.
ON TIME AND DUTY CYCLE
LIMITS
None; for reporting purposes only.
PROCEDURE
ON TIME AND DUTY CYCLE RESULTS
Mode
ON Time Period Duty Cycle
(msec) (msec)
(linear)
2.4GHz Band
BLE
0.384
0.626
0.613
Duty
Cycle
(%)
Duty Cycle
1/B
Correction Factor Minimum VBW
(dB)
(kHz)
61.34%
2.12
2.606
DUTY CYCLE PLOTS
Page 13 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.2.
DATE: 10/10/2018
IC: 5373A-RM016
99% BANDWIDTH
LIMITS
None; for reporting purposes only.
RESULTS
Channel
Low
Middle
High
Frequency
(MHz)
2402
2440
2480
99% Bandwidth
(MHz)
1.036
1.036
1.036
LOW CHANNEL
MID CHANNEL
HIGH CHANNEL
Page 14 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.3.
DATE: 10/10/2018
IC: 5373A-RM016
6 dB BANDWIDTH
LIMITS
FCC §15.407 (e)
RSS-247 5.2 (a)
The minimum 6 dB bandwidth shall be at least 500 kHz.
RESULTS
Channel
Frequency
(MHz)
6 dB Bandwidth
(MHz)
Minimum Limit
(MHz)
Low
Middle
High
2402
2440
2480
0.678
0.690
0.678
0.5
0.5
0.5
LOW CHANNEL
MID CHANNEL
HIGH CHANNEL
Page 15 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.4.
DATE: 10/10/2018
IC: 5373A-RM016
OUTPUT POWER
LIMITS
FCC §15.247 (b) (3)
RSS-247 5.4 (d)
The maximum antenna gain is less than or equal to 6 dBi, therefore the limit is 30 dBm.
TEST PROCEDURE
The transmitter output is connected to a power meter.
The cable assembly insertion loss of 11 dB (including 10 dB pad and 1 dB cable) was entered
as an offset in the power meter to allow for a gated peak reading of power.
RESULTS
Tested By:
Date:
16069_OG
7/25/2018
Channel
Frequency
Low
Middle
High
(MHz)
2402
2440
2480
Peak Power
Reading
(dBm)
-1.020
-0.964
-1.107
Limit
Margin
(dBm)
30
30
30
(dB)
-31.020
-30.964
-31.107
Page 16 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.5.
DATE: 10/10/2018
IC: 5373A-RM016
AVERAGE POWER
LIMITS
None; for reporting purposes only.
TEST PROCEDURE
The transmitter output is connected to a power meter.
The cable assembly insertion loss of 11 dB (including 10 dB pad and 1 dB cable) was entered
as an offset in the power meter to allow for a gated peak reading of power.
RESULTS
Tested By:
Date:
16069_OG
7/25/2018
Channel
Frequency
AV power
Low
Middle
High
(MHz)
2402
2440
2480
(dBm)
-1.370
-1.390
-1.460
Page 17 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.6.
DATE: 10/10/2018
IC: 5373A-RM016
POWER SPECTRAL DENSITY
LIMITS
FCC §15.247 (e)
RSS-247 (5.2) (b)
The power spectral density conducted from the transmitter to the antenna shall not be greater
than 8 dBm in any 3 kHz band during any time interval of continuous transmission.
RESULTS
Channel
Low
Middle
High
Frequency
PSD
(MHz)
(dBm/3kHz)
2402
-2.62
2440
-2.65
2480
-2.75
Limit
(dBm/3kHz)
LOW CHANNEL
Margin
(dB)
-10.62
-10.65
-10.75
MID CHANNEL
HIGH CHANNEL
Page 18 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
8.7.
DATE: 10/10/2018
IC: 5373A-RM016
CONDUCTED SPURIOUS EMISSIONS
LIMITS
FCC §15.247 (d)
RSS-247 5.5
Output power was measured based on the use of a peak measurement, therefore the required
attenuation is 20 dB.
RESULTS
Page 19 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
LOW CHANNEL BANDEDGE
OUT-OF-BAND LOW CHANNEL
IN-BAND REFERENCE LEVEL
OUT-OF-BAND MID CHANNEL
HIGH CHANNEL BANDEDGE
OUT-OF-BAND HIGH CHANNEL
Page 20 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
9. RADIATED TEST RESULTS
9.1.
LIMITS AND PROCEDURE
LIMITS
FCC §15.205 and §15.209
RSS-GEN, Section 8.9 and 8.10.
Frequency Range
(MHz)
0.009-0.490
0.490-1.705
1.705 - 30
30 - 88
88 - 216
216 - 960
Above 960
Field Strength Limit
(uV/m) at 3 m
2400/F(kHz) @ 300 m
24000/F(kHz) @ 30 m
30 @ 30m
100
150
200
500
Field Strength Limit
(dBuV/m) at 3 m
40
43.5
46
54
TEST PROCEDURE
The EUT is placed on a non-conducting table 80 cm above the ground plane for measurement
below 1GHz; 1.5 m above the ground plane for measurement above 1GHz. The antenna to EUT
distance is 3 meters. The EUT is configured in accordance with ANSI C63.10. The EUT is set to
transmit in a continuous mode.
For measurements below 1 GHz the resolution bandwidth is set to 100 kHz for peak detection
measurements or 120 kHz for quasi-peak detection measurements. Peak detection is used
unless otherwise noted as quasi-peak.
For pre-scans above 1 GHz the resolution bandwidth is set to 1 MHz; the video bandwidth is set
to 30 KHz for peak measurements.
For final measurements above 1 GHz the resolution bandwidth is set to 1 MHz; the video
bandwidth is set to 3 MHz for peak measurements and as applicable for average
measurements.
The spectrum from 1 GHz to 18 GHz is investigated with the transmitter set to the lowest,
middle, and highest channels in each applicable band. Below 1GHz and above 18GHz
emissions, the channel with the highest output power was tested.
The frequency range of interest is monitored at a fixed antenna height and EUT azimuth. The
EUT is rotated through 360 degrees to maximize emissions received. The antenna is scanned
from 1 to 4 meters above the ground plane to further maximize the emission. Measurements are
made with the antenna polarized in both the vertical and the horizontal positions.
Page 21 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
9.2.
DATE: 10/10/2018
IC: 5373A-RM016
TRANSMITTER ABOVE 1 GHz
BANDEDGE (LOW CHANNEL)
HORIZONTAL RESULT
Marker
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863 (dB/m)
Amp/Cbl/Fltr/Pad (dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Average Limit (dBuV/m)
Margin
(dB)
Peak Limit (dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 2.389
* 2.39
* 2.39
* 2.39
28.81
45.59
46.84
26.38
RMS
Pk
Pk
RMS
32.3
32.3
32.3
32.3
-21.5
-21.5
-21.5
-21.5
2.12
2.12
41.73
56.39
57.64
39.3
54
54
-12.27
-14.7
74
74
-17.61
-16.36
314
314
314
314
306
306
306
306
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
Pk - Peak detector
RMS - RMS detection
Page 22 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
VERTICAL RESULT
Marker
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863 (dB/m)
Amp/Cbl/Fltr/Pad
(dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Average Limit
(dBuV/m)
Margin
(dB)
Peak Limit (dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 2.39
* 2.389
* 2.39
* 2.388
45.79
46.2
27.56
28.57
Pk
Pk
RMS
RMS
32.3
32.3
32.3
32.3
-21.5
-21.5
-21.5
-21.5
2.12
2.12
56.59
57
40.48
41.49
54
54
-13.52
-12.51
74
74
-17.41
-17
274
274
274
274
393
393
393
393
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
Pk - Peak detector
RMS - RMS detection
Page 23 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
BANDEDGE (HIGH CHANNEL)
HORIZONTAL RESULT
Marker
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863 (dB/m)
Amp/Cbl/Fltr/Pad
(dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Average Limit
(dBuV/m)
Margin
(dB)
Peak Limit (dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 2.484
* 2.484
* 2.484
* 2.485
54.63
54.99
28.35
35.17
Pk
Pk
RMS
RMS
32.6
32.6
32.6
32.6
-21.5
-21.5
-21.5
-21.5
2.12
2.12
65.73
66.09
41.57
48.39
54
54
-12.43
-5.61
74
74
-8.27
-7.91
305
305
305
305
395
395
395
395
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
Pk - Peak detector
RMS - RMS detection
Page 24 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
VERTICAL RESULT
Marker
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863 (dB/m)
Amp/Cbl/Fltr/Pad (dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Average Limit (dBuV/m)
Margin
(dB)
Peak Limit (dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 2.484
* 2.484
* 2.484
* 2.484
55.53
55.46
26.22
34.26
Pk
Pk
RMS
RMS
32.6
32.6
32.6
32.6
-21.5
-21.5
-21.5
-21.5
2.12
2.12
66.63
66.56
39.44
47.48
54
54
-14.56
-6.52
74
74
-7.37
-7.44
281
281
281
281
377
377
377
377
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
Pk - Peak detector
RMS - RMS detection
Page 25 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
HARMONICS AND SPURIOUS EMISSIONS
LOW CHANNEL RESULTS
HORIZTONAL
VERTICAL
Page 26 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
RADIATED EMISSIONS
Radiated Emissions
Frequenc
(GHz)
Meter
Reading
(dBuV)
Det
AF T863
(dB/m)
Amp/Cbl/Fltr/
Pad (dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Avg Limit
(dBuV/m)
Margin
(dB)
Peak Limit
(dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 1.25
* 1.25
* 4.803
* 4.804
* 4.803
* 4.804
32.41
22.78
51.8
46.66
46.99
40.06
PK2
MAv1
PK2
MAv1
PK2
MAv1
28.3
28.3
34
34
34
34
-22.4
-22.4
-30.1
-30.1
-30.1
-30.1
2.12
2.12
2.12
38.31
30.8
55.7
52.68
50.89
46.08
54
54
54
-23.2
-1.32
-7.92
74
74
74
-35.69
-18.3
-23.11
183
183
147
147
301
301
105
105
307
307
227
227
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
PK2 - KDB558074 Method: Maximum Peak
MAv1 - KDB558074 Option 1 Maximum RMS Average
Page 27 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
MID CHANNEL RESULTS
HORIZTONAL
VERTICAL
Page 28 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
RADIATED EMISSIONS
Radiated Emissions
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863
(dB/m)
Amp/Cbl/Fltr/
Pad (dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Avg Limit
(dBuV/m)
Margin
(dB)
Peak Limit
(dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 4.883
* 4.884
* 4.883
* 4.884
52.3
47.28
49.61
44.06
PK2
MAv1
PK2
MAv1
34.3
34.3
34.3
34.3
-31.4
-31.4
-31.4
-31.4
2.12
2.12
55.2
52.3
52.51
49.08
54
54
-1.7
-4.92
74
74
-18.8
-21.49
138
138
282
282
256
256
335
335
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
PK2 - KDB558074 Method: Maximum Peak
MAv1 - KDB558074 Option 1 Maximum RMS Average
Page 29 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
HIGH CHANNEL RESULTS
HORIZTONAL
VERTICAL
Page 30 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
RADIATED EMISSIONS
Radiated Emissions
Frequency
(GHz)
Meter
Reading
(dBuV)
Det
AF T863
(dB/m)
Amp/Cbl/Fltr/
Pad (dB)
DC Corr (dB)
Corrected
Reading
(dBuV/m)
Avg Limit
(dBuV/m)
Margin
(dB)
Peak Limit
(dBuV/m)
PK
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
* 4.96
* 4.96
* 4.959
* 4.96
52.45
47.68
48.4
42.92
PK2
MAv1
PK2
MAv1
34.5
34.5
34.5
34.5
-30.9
-30.9
-30.9
-30.9
2.12
2.12
56.05
53.4
52
48.64
54
54
-.6
-5.36
74
74
-17.95
-22
135
135
285
285
279
279
321
321
* - indicates frequency in CFR47 Pt 15 / IC RSS-Restricted Band
PK2 - KDB558074 Method: Maximum Peak
MAv1 - KDB558074 Option 1 Maximum RMS Average
Page 31 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
9.3.
DATE: 10/10/2018
IC: 5373A-RM016
Worst Case Below 30 MHz
SPURIOUS EMISSIONS 9 kHz TO 30 MHz (WORST-CASE CONFIGURATION)
NOTE: KDB 414788 OATS and Chamber Correlation Justification
Based on FCC 15.31 (f) (2): measurements may be performed at a distance closer than
that specified in the regulations; however, an attempt should be made to avoid making
measurements in the near field.
OATs and chamber correlation testing had been performed and chamber measured test
result is the worst case test result.
Below 30 MHz Data
Trace Markers
Marker
Frequency
(MHz)
.1296
.13154
.19066
.23144
Meter
Reading
(dBuV)
30.64
29.97
45.29
45.17
Det
Loop Antenna
(dB/m)
Cbl
(dB)
Dist Corr
300m
Pk
Pk
Pk
Pk
14
14
13.9
13.9
1.4
1.4
1.5
1.5
-80
-80
-80
-80
Corrected
Reading
(dBuVolts)
-33.96
-34.63
-19.31
-19.43
Peak Limit
(dBuV/m)
Margin
(dB)
Avg Limit
(dBuV/m)
Margin
(dB)
Azimuth
(Degs)
45.37
45.24
42.01
40.33
-79.33
-79.87
-61.32
-59.76
25.37
25.24
22.01
20.33
-59.33
-59.87
-41.32
-39.76
0-360
0-360
0-360
0-360
Pk - Peak detector
Marker
Frequency
(MHz)
.58736
1.07543
18.04856
26.48706
Meter
Reading
(dBuV)
36.86
30.42
11.16
18.03
Det
Loop Antenna (dB/m)
Cbl (dB)
Dist Corr (dB) 40Log
Pk
Pk
Pk
Pk
14
14.3
14.6
12.9
1.5
1.5
1.6
1.7
-40
-40
-40
-40
Corrected
Reading
(dBuVolts)
12.36
6.22
-12.64
-7.37
QP Limit (dBuV/m)
Margin
(dB)
Azimuth
(Degs)
32.23
26.99
29.5
29.5
-19.87
-20.77
-42.14
-36.87
0-360
0-360
0-360
0-360
Pk - Peak detector
Page 32 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
9.4.
DATE: 10/10/2018
IC: 5373A-RM016
Worst Case Below 1 GHz
SPURIOUS EMISSIONS 30 TO 1000 MHz (WORST-CASE CONFIGURATION)
HORIZTONAL
VERTICAL
Page 33 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
Below 1GHz Data
Marker
Frequency
(MHz)
Meter
Reading
(dBuV)
Det
AF T407 (dB/m)
Amp/Cbl (dB)
Correcte
Reading
(dBuV/m)
QPk Limit (dBuV/m)
Margin
(dB)
Azimuth
(Degs)
Height
(cm)
Polarity
32.5932
63.0736
95.8708
156.6403
188.2259
192.5408
41.61
51.66
49.67
47.45
48.8
47.68
Pk
Pk
Pk
Pk
Pk
Pk
23.3
11.9
13.2
16.3
15.2
15.5
-28.8
-28.4
-28
-27.3
-27
-26.9
36.11
35.16
34.87
36.45
37
36.28
40
40
43.52
43.52
43.52
43.52
-3.89
-4.84
-8.65
-7.07
-6.52
-7.24
0-360
0-360
0-360
0-360
0-360
0-360
100
100
300
200
100
100
Page 34 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
9.5.
DATE: 10/10/2018
IC: 5373A-RM016
Worst Case 18-26 GHz
SPURIOUS EMISSIONS 18-26 GHz (WORST-CASE CONFIGURATION)
HORIZTONAL
VERTICAL
Page 35 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
18 – 26GHz DATA
Marker
Frequenc
(GHz)
Meter
Reading
(dBuV)
Det
T89 AF
(dB/m)
Amp/Cbl (dB)
Dist Corr
(dB)
Corrected
Reading
(dBuVolts
Avg Limit
(dBuV/m)
Margin
(dB)
Peak Limit
(dBuV/m)
PK
Margin
(dB)
19.309
21.241
23.945
18.693
21.832
23.878
36.64
35.87
37.36
35.88
36.91
37.07
Pk
Pk
Pk
Pk
Pk
Pk
32.4
33.2
33.4
32.5
33.3
33.5
-25.1
-25.3
-24.2
-24.2
-24.9
-24.1
-9.5
-9.5
-9.5
-9.5
-9.5
-9.5
34.44
34.27
37.06
34.68
35.81
36.97
54
54
54
54
54
54
-19.56
-19.73
-16.94
-19.32
-18.19
-17.03
74
74
74
74
74
74
-39.56
-39.73
-36.94
-39.32
-38.19
-37.03
Page 36 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
10.
DATE: 10/10/2018
IC: 5373A-RM016
AC POWER LINE CONDUCTED EMISSIONS
LIMITS
FCC §15.207 (a)
RSS-Gen 8.8
RESULTS
Page 37 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
LINE 1 RESULTS
Trace Markers
Range 1: Line-L1 .15 - 30MHz
Marker
Frequenc
(MHz)
Meter
Reading
(dBuV)
Det
LISN L1
LC
Cables
C1&C3
Limiter
(dB)
Corrected
Reading
dBuV
CFR 47
Part 15
Class B
QP
QP
Margin
(dB)
CFR 47
Part 15
Class B
Avg
Av(CISPR
)Margin
(dB)
10
11
12
.15675
.15675
.16575
.177
.19725
.19725
.2175
.2175
.65175
.6495
1.059
1.059
28.5
14.19
24.48
10.56
22.99
10.55
20.46
8.22
7.58
-1.32
9.63
9.21
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
.1
.1
.1
.1
.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
38.7
24.39
34.68
20.66
33.09
20.65
30.56
18.32
17.68
8.78
19.83
19.41
65.63
65.17
63.73
62.91
56
56
-26.93
-30.49
-30.64
-32.35
-38.32
-36.17
55.63
54.63
53.73
52.91
46
46
-31.24
-33.97
-33.08
-34.59
-37.22
-26.59
Qp - Quasi-Peak detector
Ca - CISPR average detection
Page 38 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
REPORT NO: 12166253-E1V3
FCC ID: SBVRM016
DATE: 10/10/2018
IC: 5373A-RM016
LINE 2 RESULTS
Trace Markers
Range 2: Line-L2 .15 - 30MHz
Marker
Frequenc
(MHz)
Meter
Reading
(dBuV)
Det
LISN L2
LC
Cables
C2&C3
Limiter
(dB)
Corrected
Reading
dBuV
CFR 47
Part 15
Class B
QP
QP
Margin
(dB)
CFR 47
Part 15
Class B
Avg
Av(CISPR
)Margin
(dB)
13
14
15
16
17
18
19
20
21
22
23
24
.15225
.15675
.16575
.177
.177
.177
.19725
.19725
.2175
.2175
1.059
1.059
26.88
13.56
24.79
12.31
23.93
12.31
21.04
10.39
18.77
8.17
9.63
9.51
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
Qp
Ca
.1
.1
.1
.1
.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
37.08
23.76
34.99
22.41
34.03
22.41
31.14
20.49
28.87
18.27
19.83
19.71
65.88
65.17
64.63
63.73
62.91
56
-28.8
-30.18
-30.6
-32.59
-34.04
-36.17
55.63
54.63
54.63
53.73
52.91
46
-31.87
-32.22
-32.22
-33.24
-34.64
-26.29
Qp - Quasi-Peak detector
Ca - CISPR average detection
Page 39 of 41
UL VERIFICATION SERVICES INC.
47173 Benicia Street, Fremont, CA 94538; USA
TEL:(510) 771-1000
FAX:(510) 661-0888
This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc.
Download: RM016 802.11a/b/g/n HT20 Client Device Test Report 1 Sonos, Inc.
Mirror Download [FCC.gov]RM016 802.11a/b/g/n HT20 Client Device Test Report 1 Sonos, Inc.
Document ID4103722
Application ID+HfueN6Mkqz2vJXIoIS4Iw==
Document Description12166253-E1V3 FCCIC Report BLE
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize283.76kB (3547007 bits)
Date Submitted2018-12-12 00:00:00
Date Available2018-12-31 00:00:00
Creation Date2018-10-11 17:41:14
Producing SoftwareMicrosoft® Word 2016
Document Lastmod2018-10-11 17:42:18
Document TitleTest Report 1
Document CreatorMicrosoft® Word 2016
Document Author: Mike Heckrotte

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.7
Linearized                      : No
Author                          : Mike Heckrotte
Create Date                     : 2018:10:11 17:41:14-07:00
Modify Date                     : 2018:10:11 17:42:18-07:00
Language                        : en-US
XMP Toolkit                     : Adobe XMP Core 5.6-c015 84.159810, 2016/09/10-02:41:30
Producer                        : Microsoft® Word 2016
Format                          : application/pdf
Title                           : 1
Creator                         : Mike Heckrotte
Creator Tool                    : Microsoft® Word 2016
Metadata Date                   : 2018:10:11 17:42:18-07:00
Document ID                     : uuid:7278B013-CD8F-4033-87CD-A3D84C4C1D1D
Instance ID                     : uuid:3dc02cde-04ff-4ef6-9235-d3289c78f6a6
Page Count                      : 39
