AEVK1 Label Diagram - FCC ID SC9AEVK1

FCC ID SC9AEVK1

rear panel

AEVK1

by General Atomics

Document preview loads when visible.

Document Details

FCC IDSC9AEVK1
Document ID483448
Document TypeID Label/Location Info
Descriptionrear panel
Document TitleFull page fax print
ApplicantGeneral Atomics
Equipment ClassAEVK1
Product CodeAEVK1
Application IDW13lBLs/ZdmXJxVhfYd5Dg==
Application PurposeOriginal Equipment
Application Date2005-06-30
Frequency Range3100-7300 MHz
FRN0004966214
Test FirmTDK RF Solutions, Inc.
Certified ByPat Carson V.P.
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-10-29
Available2005-06-30
Created2004-10-29
Modified2004-10-29
Pages1
File TypeAdobe Acrobat PDF
File Size25925
File SHA-256b5825db979fd467e65c5cf73387bddfee14689c73083206ec2eec45c3d22aaeb
PDF Metadata Authorpcarson
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows) pcarson
FCC.gov SourcesFCC.gov 483448
