FCC ID SENISC5
SPOT
by iSmart Alarm, Inc.
Grantee Code: SEN Product Code: ISC5
Latest application date: 2015-12-09
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-12-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual REV 1 | Users Manual | 2015-12-09 | PDF 348.8 KB |
| Internal Photos REV 1 | Internal Photos | 2015-12-09 | PDF 1.9 MB |
| External Photos | External Photos | 2015-12-09 | PDF 3.7 MB |
| label locatlion | ID Label/Location Info | 2015-12-09 | PDF 752 KB |
| test setup photos | Test Setup Photos | 2015-12-09 | PDF 380.6 KB |
| FCC Part 1 15.247 Report REV 1 | Test Report | 2015-12-09 | PDF 517.7 KB |
| FCC Part 2 15.247 Report REV 1 | Test Report | 2015-12-09 | PDF 2.5 MB |
| FCC Part 3 15.247 Report REV 1 | Test Report | 2015-12-09 | PDF 5.2 MB |
| FCC Part 4 15.247 Report REV 1 | Test Report | 2015-12-09 | PDF 2.9 MB |
| Request of Confidentiality | Cover Letter(s) | 2015-12-09 | PDF 671.9 KB |
| WiFi channel declaration | Cover Letter(s) | 2015-12-09 | PDF 63.8 KB |
| FCC MPE Report | RF Exposure Info | 2015-12-09 | PDF 127.5 KB |
| block diagram Metadata only | Block Diagram | PDF 63.7 KB | |
| block diagram of the WiFi module REV 1 Metadata only | Block Diagram | PDF 283.1 KB | |
| BOM Metadata only | Schematics | PDF 28.9 KB | |
| SCH REV 1 Metadata only | Schematics | PDF 1.5 MB | |
| WUBB-743GN SCH REV 1 Metadata only | Schematics | PDF 167.8 KB | |
| Operation description Metadata only | Operational Description | PDF 187.7 KB | |
| WIFI Spercification Metadata only | Operational Description | PDF 501.5 KB |
Application Information
| Application ID | bLGoiOJOEE5E89F5C+GapQ== |
|---|---|
| Final Action Date | 2015-12-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022502181 |
| Model | ISC5 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | SPOT |
| Responsible Party | Tision Tian, tiansai@jiuan.com  , 022-60526161 |
| Agent | Jane Jane Jane, GUANGZHOU GRG METROLOGY & TEST CO., LTD., caoxw@grgtest.com  , 86-20-39699960 |
| Technical Contact | Jane Cao, GUANGZHOU GRG METROLOGY & TEST CO., LTD., caoxw@grgtest.com , 86-20-39699960 |
| Test Firm | Gavin Wu, Guangzhou GRG Metrology And Test Technology LTD., wuym@grg.net.cn  , 862038699960 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is conducted. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz Bandwidth for WiFi function. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| bLGoiOJOEE5E89F5C+GapQ== | 2015-12-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0521200 | 15C |
Grants
TCB Grant - Application bLGoiOJOEE5E89F5C+GapQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 12/09/2015 Application Dated: 12/07/2015 |
| iSmart Alarm, Inc. |
| 1290 Kifer Road Suite 306, Sunnyvale, CA 94086, US |
| Sunnyvale, CA 94086 |
| Attention: Tision Tian |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SENISC5 |
| Name of Grantee: | iSmart Alarm, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | SPOT |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.05212 |
| Power output is conducted. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz Bandwidth for WiFi function. |
EAS Grant - Application bLGoiOJOEE5E89F5C+GapQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
iSmart Alarm, Inc. 1290 Kifer Road Suite 306, Sunnyvale, CA 94086, US Sunnyvale, CA 94086 United States |
Date of Grant: 12/09/2015 Application Dated: 12/07/2015 |
| Attention: Tision Tian |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SENISC5 |
| Name of Grantee: | iSmart Alarm, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | SPOT |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.05212 |
| Power output is conducted. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz Bandwidth for WiFi function. |
