201708I512 Smart Phone Test Setup Photos - FCC ID SG7201708I512

FCC ID SG7201708I512

Test Setup Photos

Smart Phone

by Haier Telecom (Qingdao) Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDSG7201708I512
Document ID3575752
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantHaier Telecom (Qingdao) Co., Ltd.
Equipment ClassSmart Phone
Product Code201708I512
Application ID7plKRFchL177Lm3M+RqQtA==
Application PurposeOriginal Equipment
Application Date2017-09-22
Frequency Range2402-2480 MHz
FRN0017353921
Test FirmShenzhen NTEK Testing Technology Co., Ltd.
Certified BySophia Chen Global Approvals Engineer, NTEK Testing Technology
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/21/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-09-22
Available2018-03-21
Created2017-09-14
Modified2017-09-14
Pages2
File TypeAdobe Acrobat PDF
File Size264076
File SHA-2561b2e60acd9d40c9e71c4cdc5eb658067b32bc970023e9ba70c293d04a3be498e
PDF Metadata Authorntek202
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3575752
