BCD433 PLANAR-B, PLANAR-C, PLANAR-D Teardown... - FCC ID SJ7BCD433
FCC ID SJ7BCD433
Internal Photos D
PLANAR-B, PLANAR-C, PLANAR-D
Document preview loads when visible.
Document Details
| FCC ID | SJ7BCD433 |
|---|---|
| Document ID | 3089470 |
| Document Type | Internal Photos |
| Description | Internal Photos D |
| Document Title | Internal Photos_PLANAR_D_Completedx |
| Applicant | NBB Controls + Components AG |
| Equipment Class | PLANAR-B, PLANAR-C, PLANAR-D |
| Product Code | BCD433 |
| Application ID | OtbKrCPLa9E0rnA5Ax2zKQ== |
| Application Purpose | Original Equipment |
| Application Date | 2016-08-05 |
| Frequency Range | 433.1-434.75 MHz |
| FRN | 0011577384 |
| Test Firm | Washington Laboratories, Ltd. |
| Certified By | Thomas Burchard |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-08-05 |
| Available | 2016-08-05 |
| Created | 2017-12-11 |
| Modified | 2017-12-11 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 395832 |
| File SHA-256 | 04487e529053b9804aa675bc4cf512b0427ad85c78ea93fc3faeb3cb10f7f2f1 |
| PDF Metadata Author | KarenS |
| PDF Metadata Producer | GPL Ghostscript 9.18 KarenS |
| FCC.gov Sources | FCC.gov 3089470 |
