HYPR915 HyPRO Teardown Internal Photos - FCC ID SJ7HYPR915
FCC ID SJ7HYPR915
Internal Photos
HyPRO
Document preview loads when visible.
Document Details
| FCC ID | SJ7HYPR915 |
|---|---|
| Document ID | 3063798 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal Photos_HyPro_redlinedx |
| Applicant | NBB Controls + Components AG |
| Equipment Class | HyPRO |
| Product Code | HYPR915 |
| Application ID | 3O+WAJ/5on1h61hEFwswQw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-07-14 |
| Frequency Range | 915-916.65 MHz |
| FRN | 0011577384 |
| Test Firm | Washington Laboratories, Ltd. |
| Certified By | Thomas Burchard |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-07-14 |
| Available | 2016-07-14 |
| Created | 2016-05-27 |
| Modified | 2016-05-27 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 534134 |
| File SHA-256 | 1d2277c8e2c31e13cb945ee06daa292fd6b499c0a5a64308954eacdd44ebd1d1 |
| PDF Metadata Author | KarenS |
| PDF Metadata Producer | KarenS Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 3063798 |
