FCC ID SNL-BLWM
2.4GHz WiFi module
by GRAUPNER CO., LTD.
Grantee Code: SNL Product Code: BLWM
Latest application date: 2017-03-10
Device Images
FCC ID Device Details
| FCC ID | SNL-BLWM |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | SNL |
| Product Code | BLWM |
| Applicant Business | GRAUPNER CO., LTD. 🇰🇷 |
| Related Domains |  sjpropo.com |
| Equipment Class | 2.4GHz WiFi module |
| Test Firm | Shenzhen CTL Testing Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-03-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_BL-WM UserMan | Users Manual | 2017-03-10 | PDF 128.4 KB |
| 09_BL-WM IntPho | Internal Photos | 2017-03-10 | PDF 492.5 KB |
| 08_BL-WM ExtPho | External Photos | 2017-03-10 | PDF 442.5 KB |
| 06-07_BL-WM LabelSmpl-Loc | ID Label/Location Info | 2017-03-10 | PDF 182.3 KB |
| 17_BL-WM AntSpec,r1 | Operational Description | 2017-03-10 | PDF 36.3 KB |
| 10_BL-WM TSup | Test Setup Photos | 2017-03-10 | PDF 300.2 KB |
| 14_BL-WM TestRpt DTS,r3 | Test Report | 2017-03-10 | PDF 2.4 MB |
| 18_BL-WM RFExp,r3 | RF Exposure Info | 2017-03-10 | PDF 173.3 KB |
| 12_BL-WM BlkDia,r1 Metadata only | Block Diagram | PDF 125.1 KB | |
| 13_BL-WM Schem Metadata only | Schematics | PDF 145.7 KB | |
| 11_BL-WM OpDes,r1 Metadata only | Operational Description | PDF 425.5 KB | |
| 16_BL-WM PartsLst Metadata only | Parts List/Tune Up Info | PDF 41.3 KB |
Application Information
| Application ID | uK62hPTBC7DYXa6l80YVwA== |
|---|---|
| Final Action Date | 2017-03-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0026481333 |
| Model | BLWM |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 2.4GHz WiFi module |
| Responsible Party | Durk Churl Gahng, duck7e@sjpropo.com , 82-32-623-0728 |
| Test Firm | Tracy Qi, Shenzhen CTL Testing Technology Co., Ltd., qihui@ctl-lab.com  , 86-755-89486194 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device supports only 20MHz bandwidth operation. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| uK62hPTBC7DYXa6l80YVwA== | 2017-03-10 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Rules |
|---|---|---|---|
| 2412-2462 MHz | 0.0125000 | ppm | 15C |
Grants
TCB Grant - Application uK62hPTBC7DYXa6l80YVwA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 03/10/2017 Application Dated: 03/10/2017 |
| GRAUPNER CO., LTD. |
| 202Dong 8th F,18, Bucheon-ro 198beon-gil, |
| Wonmi-gu |
| Bucheon-si, Gyeonggi-do,, South Korea |
| Attention: Durk Churl Gahng |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SNL-BLWM |
| Name of Grantee: | GRAUPNER CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4GHz WiFi module |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0125 |
| Power listed is conducted. This device supports only 20MHz bandwidth operation. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
EAS Grant - Application uK62hPTBC7DYXa6l80YVwA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
GRAUPNER CO., LTD. 202Dong 8th F,18, Bucheon-ro 198beon-gil, Wonmi-gu Bucheon-si, Gyeonggi-do,, South Korea |
Date of Grant: 03/10/2017 Application Dated: 03/10/2017 |
| Attention: Durk Churl Gahng |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SNL-BLWM |
| Name of Grantee: | GRAUPNER CO., LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | 2.4GHz WiFi module |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0125 |
| Power listed is conducted. This device supports only 20MHz bandwidth operation. SAR evaluation is valid for mobile applications only (minimum distance of 20cm to human bodies). |
