NXP781 Pager Block Diagram - FCC ID SNXNXP781

FCC ID SNXNXP781

Block Diagram

Pager

by Maxtel Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDSNXNXP781
Document ID483467
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantMaxtel Co., Ltd.
Equipment ClassPager
Product CodeNXP781
Application IDlPg/OcPXFzR/Qiy5go3U4Q==
Application PurposeOriginal Equipment
Application Date2004-10-29
Frequency Range137.925-170.175 MHz
FRN0011964079
Test FirmONETECH Corp.
Certified ByY.K. Kwon Manager (Agent)
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-10-29
Available2004-10-29
Created2004-10-29
Modified2004-10-29
Pages1
File TypeAdobe Acrobat PDF
File Size51657
File SHA-2569b0fb0c50da749ecfd94efdae831971fabaf189f25f90b4e213085afa39692ca
PDF Metadata ProducerAdobe Acrobat 6.0 Paper Capture HP PrecisionScan Pro 2.5
FCC.gov SourcesFCC.gov 483467
