201548 BT Base Station for BT Headset Test... - FCC ID SOM-201548

FCC ID SOM-201548

Test Setup Photos

BT Base Station for BT Headset

by VXI Corporation

Document preview loads when visible.

Document Details

FCC IDSOM-201548
Document ID490342
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleTestsetup_photos_Base
ApplicantVXI Corporation
Equipment ClassBT Base Station for BT Headset
Product Code201548
Application IDkeHpAJOtkF0d4SUR04r+sQ==
Application PurposeOriginal Equipment
Application Date2004-11-22
Frequency Range2402-2480 MHz
FRN0012094462
Test FirmCetecom Inc.
Certified ByLothar Schmidt
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-11-22
Available2004-11-22
Created2004-11-16
Modified2004-11-16
Pages3
File TypeAdobe Acrobat PDF
File Size199458
File SHA-256fbe3b27ea8465e8bf3718b08ff2fa22ca0afd7947a0025e316cdbba653fdb24d
PDF Metadata AuthorHSidhu
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows) HSidhu
FCC.gov SourcesFCC.gov 490342
