Internal photos
Portable Media Player with WiFi
by Archos SA
Document preview loads when visible.
Document Details
| FCC ID | SOV42618 |
|---|---|
| Document ID | 700495 |
| Document Type | Internal Photos |
| Description | Internal photos |
| Document Title | Annex No 2 _Internal photographs_ |
| Applicant | Archos SA |
| Equipment Class | Portable Media Player with WiFi |
| Product Code | 42618 |
| Application ID | +zPV6W8mpxQPdTpNm8Un1w== |
| Application Purpose | Original Equipment |
| Application Date | 2006-09-01 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0012123238 |
| Test Firm | m. dudde hochfrequenz-technik |
| Certified By | Ralf Trepper Technical engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2006-09-01 |
| Available | 2006-09-01 |
| Created | 2006-08-23 |
| Modified | 2006-08-23 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 269874 |
| File SHA-256 | 522bdcbeaf1b7405be3f0b6b98bd4e2fe5cd5da81b9e76570131e3a01133aec3 |
| PDF Metadata Author | Ralf Trepper |
| PDF Metadata Producer | Acrobat Distiller 7.0.5 (Windows) Ralf Trepper |
| FCC.gov Sources | FCC.gov 700495 |
