L130 GSM/WCDMA Multi-Mode Digital Mobile Phone... - FCC ID SRQ-L130

FCC ID SRQ-L130

Test Setup photo

GSM/WCDMA Multi-Mode Digital Mobile Phone

by ZTE Corporation

Document preview loads when visible.

Document Details

FCC IDSRQ-L130
Document ID4122505
Document TypeTest Setup Photos
DescriptionTest Setup photo
Document TitleSRQ-L130 Test Setup Photo
ApplicantZTE Corporation
Equipment ClassGSM/WCDMA Multi-Mode Digital Mobile Phone
Product CodeL130
Application IDGMZjF0cEzaOvifR+ph8znQ==
Application PurposeOriginal Equipment
Application Date2018-12-29
Frequency Range2402-2480 MHz
FRN0022602015
Test FirmThe State Radio_monitoring_center Testing Center
Certified ByYu Gong
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-12-28
Available2018-12-29
Created2018-12-26
Modified2018-12-26
Pages7
File TypeAdobe Acrobat PDF
File Size839850
File SHA-256df67fda5048c062fa94cc3597a68e099450398fe198fa274bfc8427043e1f652
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows) Administrator
FCC.gov SourcesFCC.gov 4122505
