Z826 WCDMA/LTE Multi-Mode Digital Mobile Phone... - FCC ID SRQ-Z826

FCC ID SRQ-Z826

Test setup photo_DTS_WLAN

WCDMA/LTE Multi-Mode Digital Mobile Phone

by ZTE Corporation

Document preview loads when visible.

Document Details

FCC IDSRQ-Z826
Document ID2441883
Document TypeTest Setup Photos
DescriptionTest setup photo_DTS_WLAN
Document TitleFR492505C_R01_Part15C_ZTE_ZTE_Appendix A
ApplicantZTE Corporation
Equipment ClassWCDMA/LTE Multi-Mode Digital Mobile Phone
Product CodeZ826
Application IDpOWNByaXCrWsK/iNXBpKFQ==
Application PurposeOriginal Equipment
Application Date2014-11-13
Frequency Range2402-2480 MHz
FRN0022602015
Test FirmSPORTON INTERNATIONAL(KUN SHAN)INC.
Certified ByMichael Lin Vice President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date05/12/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-11-12
Available2015-05-12
Created2014-11-10
Modified2014-11-10
Pages2
File TypeAdobe Acrobat PDF
File Size618802
File SHA-256f60e16aa11310f8e49fe5db586dd252e0e5d71f85ed676b8a31f3ea17a0ed3c3
PDF Metadata AuthorJaneChiu
PDF Metadata ProducerJaneChiu Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 2441883
