FCC ID SRS-M80-EA2
Dart Radio Modem
by Raveon Technologies, Incorporated
Grantee Code: SRS Product Code: M80EA2
Latest application date: 2016-02-29
Device Images
FCC ID Device Details
| FCC ID | SRS-M80-EA2 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | SRS |
| Product Code | M80EA2 |
| Applicant Business | Raveon Technologies, Incorporated 🇺🇸 |
| Related Domains |  raveon.com |
| Equipment Class | Dart Radio Modem |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 854-861 MHz | Original Equipment | 2016-02-29 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-02-29 | PDF 1.1 MB |
| Internal Photos | Internal Photos | 2016-02-29 | PDF 671 KB |
| External Photos | External Photos | 2016-02-29 | PDF 1.9 MB |
| Label | ID Label/Location Info | 2016-02-29 | PDF 1.9 MB |
| Label Location | ID Label/Location Info | 2016-02-29 | PDF 3.5 MB |
| Test Setup Photos | Test Setup Photos | 2016-02-29 | PDF 946.7 KB |
| Test Report | Test Report | 2016-02-29 | PDF 432.4 KB |
| Agent Authorisation Letter | Cover Letter(s) | 2016-02-29 | PDF 109.4 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-02-29 | PDF 46.5 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-02-29 | PDF 136.4 KB |
| RF Exposure Report | RF Exposure Info | 2016-02-29 | PDF 185.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 26 KB | |
| Schematics Metadata only | Schematics | PDF 223 KB | |
| Operational Description Metadata only | Operational Description | PDF 114.3 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 154.9 KB | |
| Tune Up Metadata only | Parts List/Tune Up Info | PDF 566.2 KB |
Application Information
| Application ID | pxH8v1fH8Gzs6YtI3+i9+g== |
|---|---|
| Final Action Date | 2016-02-29 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0012260501 |
| Model | M80-EA2 |
| Frequency Range | 854-861 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | Dart Radio Modem |
| Responsible Party | John Richard Sonnenberg, CEO, JS@RAVEON.COM , 760-807-3885 |
| TCB Email | VKerai@tuvam.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 49 cm for 0dBi antenna or 100 cm for 0 to 6dBi antenna from all persons. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF Exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| pxH8v1fH8Gzs6YtI3+i9+g== | 2016-02-29 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application pxH8v1fH8Gzs6YtI3+i9+g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV SUD BABT Octagon House, Concorde Way, Segensworth North, Fareham, PO15 5RL United Kingdom |
Date of Grant: 02/29/2016 Application Dated: 02/29/2016 |
| Raveon Technologies, Incorporated |
| 2320 Cousteau Court |
| Vista, CA 92081 |
| Attention: John Sonnenberg , CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SRS-M80-EA2 |
| Name of Grantee: | Raveon Technologies, Incorporated |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Dart Radio Modem |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90 | 854.0 - 861.0 | 3.0 | 0.1 PM | 8K20F1D | |
| 90 | 854.0 - 861.0 | 3.0 | 0.1 PM | 13K20F1 |
| Single Modular Approval. Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 49 cm for 0dBi antenna or 100 cm for 0 to 6dBi antenna from all persons. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF Exposure compliance. |
EAS Grant - Application pxH8v1fH8Gzs6YtI3+i9+g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Raveon Technologies, Incorporated 2320 Cousteau Court Vista, CA 92081 United States |
Date of Grant: 02/29/2016 Application Dated: 02/29/2016 |
| Attention: John Sonnenberg , CEO |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SRS-M80-EA2 |
| Name of Grantee: | Raveon Technologies, Incorporated |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | Dart Radio Modem |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 90 | 854.0 - 861.0 | 3.0 | 0.1 PM | 8K20F1D | |
| 90 | 854.0 - 861.0 | 3.0 | 0.1 PM | 13K20F1 |
| Single Modular Approval. Output power is conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 49 cm for 0dBi antenna or 100 cm for 0 to 6dBi antenna from all persons. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF Exposure compliance. |
| Mail To: |
