M1X1708 Mavic Pro Platinum Test Setup Photos - FCC ID SS3-M1X1708

FCC ID SS3-M1X1708

Setup Photos

Mavic Pro Platinum

by SZ DJI TECHNOLOGY CO., LTD

Document preview loads when visible.

Document Details

FCC IDSS3-M1X1708
Document ID3555695
Document TypeTest Setup Photos
DescriptionSetup Photos
Document TitleTest Setup Photos_DTS
ApplicantSZ DJI TECHNOLOGY CO., LTD
Equipment ClassMavic Pro Platinum
Product CodeM1X1708
Application IDMA6Ltn/YEiVc8aSlgog1PA==
Application PurposeOriginal Equipment
Application Date2017-09-11
Frequency Range2403.5-2477.5 MHz
FRN0022596753
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByXi Xiang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/26/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartYes
Submitted2017-09-11
Available2017-10-26
Created2018-01-04
Modified2018-01-04
Pages1
File TypeAdobe Acrobat PDF
File Size101643
File SHA-256214c66ae8a849cfb6ff4e9508f85dee184103277354994550286dc3b962a55a3
PDF Metadata Authorivan
PDF Metadata ProducerGPL Ghostscript 9.18 ivan
FCC.gov SourcesFCC.gov 3555695
